IXTQ470P2
Symbol
Test Conditions
Characteristic Values
TO-3P (IXTQ) Outline
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
23
36
S
Ciss
Coss
Crss
5400
545
44
pF
pF
pF
td(on)
tr
td(off)
tf
23
12
42
9
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 3Ω (External)
Qg(on)
Qgs
88
30
31
nC
nC
nC
Pins: 1 - Gate
2 - Drain
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
3 - Source 4 - Drain
Qgd
RthJC
RthCS
0.15 °C/W
°C/W
0.25
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
42
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
168
1.5
V
400
ns
IF = 21A, -di/dt = 100A/μs
VR = 100V, VGS = 0V
Note 1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
