2SK4077-ZK-E1-AY

型号：

2SK4077-ZK-E1-AY

品牌：

NEC[ NEC ]

页数：

8 页

PDF大小：

169 K

下载PDF手册
DATA SHEET
MOS FIELD EFFECT TRANSISTOR
2SK4077
SWITCHING
N-CHANNEL POWER MOS FET
DESCRIPTION
The 2SK4077 is N-channel MOS Field Effect Transistor designed for high current switching applications.
ORDERING INFORMATION
LEAD PLATING
Pure Sn (Tin)
Pure Sn (Tin)
PACKING
PART NUMBER
PACKAGE
2SK4077-ZK-E1-AY Note
2SK4077-ZK-E2-AY Note
Tape 2500 p/reel
Tape 2500 p/reel
TO-252 (MP-3ZK) typ. 0.27 g
TO-252 (MP-3ZK) typ. 0.27 g
Note Pb-free (This product does not contain Pb in external electrode.)
FEATURES
• Low on-state resistance
RDS(on)1 = 20 mΩ MAX. (VGS = 10 V, ID = 10 A)
RDS(on)2 = 35 mΩ MAX. (VGS = 4.5 V, ID = 5 A)
• Low input capacitance
(TO-252)
Ciss = 800 pF TYP.
• Logic level drive type
• Built in gate to source protection diode
ABSOLUTE MAXIMUM RATINGS (TA = 25°C)
Drain to Source Voltage (VGS = 0 V)
Gate to Source Voltage (VDS = 0 V)
Drain Current (DC) (TC = 25°C)
Drain Current (pulse) Note1
VDSS
VGSS
ID(DC)
ID(pulse)
PT1
40
V
V
20
20
A
40
A
Total Power Dissipation (TC = 25°C)
Total Power Dissipation (TA = 25°C)
Channel Temperature
20
W
W
°C
°C
A
PT2
1.0
150
Tch
Storage Temperature
Tstg
−55 to +150
10
Single Avalanche Current Note2
Single Avalanche Energy Note2
IAS
EAS
10
mJ
Notes 1. PW ≤ 10 μs, Duty Cycle ≤ 1%
2. Starting Tch = 25°C, VDD = 20 V, RG = 25 Ω, VGS = 20 → 0 V, L=100 μH
THERMAL RESISTANCE
Channel to Case Thermal Resistance
Channel to Ambient Thermal Resistance
Rth(ch-C)
6.25
125
°C/W
°C/W
Rth(ch-A)
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. D18461EJ1V0DS00 (1st edition)
Date Published November 2006 NS CP(K)
Printed in Japan
2006
2SK4077
ELECTRICAL CHARACTERISTICS (TA = 25°C)
CHARACTERISTICS
Zero Gate Voltage Drain Current
Gate Leakage Current
SYMBOL
TEST CONDITIONS
VDS = 40 V, VGS = 0 V
MIN.
TYP.
MAX.
UNIT
μA
μA
V
IDSS
1
IGSS
VGS = 20 V, VDS = 0 V
VDS = 10 V, ID = 1 mA
VDS = 10 V, ID = 4 A
VGS = 10 V, ID = 10 A
VGS = 4.5 V, ID = 5 A
10
2.5
Gate Cut-off Voltage
VGS(off)
| yfs |
1.5
3.2
2.0
6.3
16
Forward Transfer Admittance Note
Drain to Source On-state Resistance Note
S
RDS(on)1
20
35
mΩ
mΩ
RDS(on)2
22
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Turn-on Delay Time
Rise Time
Ciss
Coss
Crss
td(on)
tr
VDS = 10 V
VGS = 0 V
800
130
88
11
4
pF
pF
pF
ns
ns
ns
ns
nC
nC
nC
V
f = 1 MHz
VDD = 20 V, ID = 10 A
VGS = 10 V
RG = 0 Ω
Turn-off Delay Time
Fall Time
td(off)
tf
29
4
Total Gate Charge
QG
VDD = 32 V
18
3
Gate to Source Charge
Gate to Drain Charge
Body Diode Forward Voltage Note
Reverse Recovery Time
Reverse Recovery Charge
Note Pulsed
QGS
QGD
VF(S-D)
trr
VGS = 10 V
ID = 20 A
6
IF = 20 A, VGS = 0 V
IF = 20 A, VGS = 0 V
di/dt = 100 A/μs
0.9
20
20
1.5
ns
nC
Qrr
TEST CIRCUIT 1 AVALANCHE CAPABILITY
TEST CIRCUIT 2 SWITCHING TIME
D.U.T.
L
D.U.T.
V
V
GS
RG
= 25 Ω
50 Ω
R
L
90%
90%
V
GS
Wave Form
V
GS
10%
90%
0
R
G
PG.
VDD
PG.
GS = 20 → 0 V
VDD
V
DS
V
DS
V
0
GS
BVDSS
10% 10%
V
DS
Wave Form
0
I
AS
V
DS
I
D
τ
t
d(on)
t
r
t
d(off)
tf
V
DD
t
on
toff
τ = 1
μs
Duty Cycle ≤ 1%
Starting Tch
TEST CIRCUIT 3 GATE CHARGE
D.U.T.
= 2 mA
I
G
RL
50 Ω
PG.
VDD
2
Data Sheet D18461EJ1V0DS
2SK4077
TYPICAL CHARACTERISTICS (TA = 25°C)
DERATING FACTOR OF FORWARD BIAS
SAFE OPERATING AREA
TOTAL POWER DISSIPATION vs.
CASE TEMPERATURE
120
100
80
60
40
20
0
25
20
15
10
5
0
0
25
50
75 100 125 150 175
0
25
50
75 100 125 150 175
TC - Case Temperature - °C
TC - Case Temperature - °C
FORWARD BIAS SAFE OPERATING AREA
100
10
1
I
D(pulse)
I
D(DC)
Power Dissipation Limited
T
C
= 25°C
Single Pulse
0.1
0.1
1
10
100
VDS - Drain to Source Voltage – V
TRANSIENT THERMAL RESISTANCE vs. PULSE WIDTH
1000
100
10
R
th(ch-A) = 125 °C/Wi
Rth(ch-C) = 6.25 °C/Wi
1
Single pulse
100 1000
0.1
100 μ
1 m
10 m
100 m
1
10
PW - Pulse Width - s
3
Data Sheet D18461EJ1V0DS
2SK4077
DRAIN CURRENT vs.
FORWARD TRANSFER CHARACTERISTICS
DRAIN TO SOURCE VOLTAGE
80
60
40
20
0
100
10
T
A
= −55°C
25°C
75°C
150°C
V
GS = 10 V
1
4.5 V
0.1
0.01
V
DS = 10 V
Pulsed
Pulsed
2.5
1
2
3
4
5
0
0.5
1
1.5
2
3
VGS - Gate to Source Voltage - V
VDS - Drain to Source Voltage - V
GATE CUT-OFF VOLTAGE vs.
CHANNEL TEMPERATURE
FORWARD TRANSFER ADMITTANCE vs.
DRAIN CURRENT
2.5
2
100
10
1
TA
= 150°C
75°C
1.5
1
25°C
−55°C
V
DS = 10 V
0.5
V
DS = 10 V
D
I = 1 mA
Pulsed
0
-100
0
100
200
0.1
1
10
100
Tch - Channel Temperature - °C
ID - Drain Current - A
DRAIN TO SOURCE ON-STATE RESISTANCE vs.
DRAIN CURRENT
DRAIN TO SOURCE ON-STATE RESISTANCE vs.
GATE TO SOURCE VOLTAGE
40
40
Pulsed
Pulsed
30
30
I
D
= 4 A
10 A
20 A
V
GS = 4.5 V
20
10
0
20
10
0
10V
0.1
1
10
100
0
5
10
15
20
ID - Drain Current - A
VGS - Gate to Source Voltage - V
4
Data Sheet D18461EJ1V0DS
2SK4077
DRAIN TO SOURCE ON-STATE RESISTANCE vs.
CHANNEL TEMPERATURE
CAPACITANCE vs. DRAIN TO SOURCE VOLTAGE
40
10000
VGS = 0 V
f = 1 MHz
Pulsed
30
20
10
0
I = 5 A, VGS = 4.5 V
D
Ciss
1000
100
10
Coss
Crss
10 A, 10 V
-100
-50
0
50
100
150
200
0.1
1
10
100
Tch - Channel Temperature - °C
VDS - Drain to Source Voltage - V
SWITCHING CHARACTERISTICS
DYNAMIC INPUT/OUTPUT CHARACTERISTICS
40
12
10
8
1000
100
10
VDD = 20 V
VGS = 10 V
35
30
25
20
15
10
5
V
DD = 32 V
20 V
RG = 0
Ω
8 V
td(off)
td(on)
6
tf
V
GS
4
V
DS
I
D
= 20 A
2
tr
Pulsed
1
0
0
0.1
1
10
100
0
5
10
15
20
ID - Drain Current - A
QG - Gate Charge - nC
SOURCE TO DRAIN DIODE
FORWARD VOLTAGE
REVERSE RECOVERY TIME vs.
DIODE FORWARD CURRENT
100
10
1
100
10
1
VGS = 10 V
0 V
di/dt = 100 A/μs
VGS = 0 V
Pulsed
0.1
0.1
1
10
100
0
0.5
1
1.5
IF – Diode Forward Current - A
VF(S-D) - Source to Drain Voltage - V
5
Data Sheet D18461EJ1V0DS
2SK4077
PACKAGE DRAWING (Unit: mm)
TO-252 (MP-3ZK)
2.3 0.1
6.5 0.2
5.1 TYP.
4.3 MIN.
0.5 0.1
No Plating
4
1
2
3
No Plating
0.76 0.12
1.14 MAX.
0 to 0.25
0.5 0.1
2.3 2.3
1.0
1. Gate
2. Drain
3. Source
4. Fin (Drain)
EQUIVALENT CIRCUIT
Drain
Body
Diode
Gate
Gate
Protection
Diode
Source
Remark The diode connected between the gate and source of the transistor serves as a protector against ESD.
When this device actually used, an additional protection circuit is externally required if a voltage exceeding
the rated voltage may be applied to this device.
6
Data Sheet D18461EJ1V0DS
2SK4077
TAPE INFORMATION
There are two types (-E1, -E2) of taping depending on the direction of the device.
Draw-out side
Reel side
MARKING INFORMATION
Abbreviation of part number
Pb-free plating marking
K4077
Lot code
RECOMMENDED SOLDERING CONDITIONS
The 2SK4077 should be soldered and mounted under the following recommended conditions.
For soldering methods and conditions other than those recommended below, please contact an NEC Electronics
sales representative.
For technical information, see the following website.
Semiconductor Device Mount Manual (http://www.necel.com/pkg/en/mount/index.html)
Recommended
Soldering Method
Infrared reflow
Soldering Conditions
Condition Symbol
IR60-00-3
Maximum temperature (Package's surface temperature): 260°C or below
Time at maximum temperature: 10 seconds or less
Time of temperature higher than 220°C: 60 seconds or less
Preheating time at 160 to 180°C: 60 to 120 seconds
Maximum number of reflow processes: 3 times
Maximum chlorine content of rosin flux (percentage mass): 0.2% or less
Maximum temperature (Pin temperature): 350°C or below
Time (per side of the device): 3 seconds or less
Partial heating
P350
Maximum chlorine content of rosin flux: 0.2% (wt.) or less
7
Data Sheet D18461EJ1V0DS
2SK4077
•
The information in this document is current as of November, 2006. The information is subject to
change without notice. For actual design-in, refer to the latest publications of NEC Electronics data
sheets or data books, etc., for the most up-to-date specifications of NEC Electronics products. Not
all products and/or types are available in every country. Please check with an NEC Electronics sales
representative for availability and additional information.
• No part of this document may be copied or reproduced in any form or by any means without the prior
written consent of NEC Electronics. NEC Electronics assumes no responsibility for any errors that may
appear in this document.
•
NEC Electronics does not assume any liability for infringement of patents, copyrights or other intellectual
property rights of third parties by or arising from the use of NEC Electronics products listed in this document
or any other liability arising from the use of such products. No license, express, implied or otherwise, is
granted under any patents, copyrights or other intellectual property rights of NEC Electronics or others.
Descriptions of circuits, software and other related information in this document are provided for illustrative
purposes in semiconductor product operation and application examples. The incorporation of these
circuits, software and information in the design of a customer's equipment shall be done under the full
responsibility of the customer. NEC Electronics assumes no responsibility for any losses incurred by
customers or third parties arising from the use of these circuits, software and information.
•
• While NEC Electronics endeavors to enhance the quality, reliability and safety of NEC Electronics products,
customers agree and acknowledge that the possibility of defects thereof cannot be eliminated entirely. To
minimize risks of damage to property or injury (including death) to persons arising from defects in NEC
Electronics products, customers must incorporate sufficient safety measures in their design, such as
redundancy, fire-containment and anti-failure features.
• NEC Electronics products are classified into the following three quality grades: "Standard", "Special" and
"Specific".
The "Specific" quality grade applies only to NEC Electronics products developed based on a customer-
designated "quality assurance program" for a specific application. The recommended applications of an NEC
Electronics product depend on its quality grade, as indicated below. Customers must check the quality grade of
each NEC Electronics product before using it in a particular application.
"Standard": Computers, office equipment, communications equipment, test and measurement equipment, audio
and visual equipment, home electronic appliances, machine tools, personal electronic equipment
and industrial robots.
"Special": Transportation equipment (automobiles, trains, ships, etc.), traffic control systems, anti-disaster
systems, anti-crime systems, safety equipment and medical equipment (not specifically designed
for life support).
"Specific": Aircraft, aerospace equipment, submersible repeaters, nuclear reactor control systems, life
support systems and medical equipment for life support, etc.
The quality grade of NEC Electronics products is "Standard" unless otherwise expressly specified in NEC
Electronics data sheets or data books, etc. If customers wish to use NEC Electronics products in applications
not intended by NEC Electronics, they must contact an NEC Electronics sales representative in advance to
determine NEC Electronics' willingness to support a given application.
(Note)
(1)
"NEC Electronics" as used in this statement means NEC Electronics Corporation and also includes its
majority-owned subsidiaries.
(2)
"NEC Electronics products" means any product developed or manufactured by or for NEC Electronics (as
defined above).
M8E 02. 11-1
厂商 型号 描述 页数 下载

PANASONIC

 		2SK0065 为在低频率阻抗变换[ For Impedance Conversion In Low Frequency ] 3 页

ETC

 		2SK0065(2SK65) 小信号デバイス - 小信号FET - 接合形场效应管\n[ 小信号デバイス － 小信号FET － 接合形FET ] 3 页

ETC

 		2SK0065P 晶体管| JFET | N沟道| 12V V（ BR ） DSS | 40uA的我（ DSS ） | SPAKVAR\n[ TRANSISTOR | JFET | N-CHANNEL | 12V V(BR)DSS | 40UA I(DSS) | SPAKVAR ] 3 页

ETC

 		2SK0065Q 晶体管| JFET | N沟道| 12V V（ BR ） DSS | 150UA我（ DSS ） | SPAKVAR\n[ TRANSISTOR | JFET | N-CHANNEL | 12V V(BR)DSS | 150UA I(DSS) | SPAKVAR ] 3 页

PANASONIC

 		2SK0123 为在低频率阻抗变换[ For Impedance Conversion In Low Frequency ] 3 页

ETC

 		2SK0123(2SK123) 小信号器件 - 小信号场效应管 - 场效应管结\n[ Small-signal device - Small-signal FETs - Junction FETs ] 3 页

PANASONIC

 		2SK0198 对于低频放大[ For Low-Frequency Amplification ] 3 页

ETC

 		2SK0198(2SK198) 2SK0198 （ 2SK198 ） - N沟道结型场效应管\n[ 2SK0198 (2SK198) - N-Channel Junction FET ] 3 页

PANASONIC

 		2SK0198P [ Small Signal Field-Effect Transistor, 0.02A I(D), 30V, 1-Element, N-Channel, Silicon, Junction FET, TO-236, ROHS COMPLIANT, MINI3-G1, SC-59, 3 PIN ] 3 页

PANASONIC

 		2SK0198Q [ Small Signal Field-Effect Transistor, 0.02A I(D), 30V, 1-Element, N-Channel, Silicon, Junction FET, TO-236, ROHS COMPLIANT, MINI3-G1, SC-59, 3 PIN ] 3 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.208930s
