IXTA80N075L2 IXTP80N075L2
IXTH80N075L2
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
24
30
36
S
Ciss
Coss
Crss
3600
935
pF
pF
pF
325
RGi
Integrated Gate Input Resistor
1.2
td(on)
tr
td(off)
tf
15
35
40
12
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 0 (External)
Qg(on)
Qgs
103
14
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
48
RthJC
RthCS
0.35 C/W
TO-220
TO-247
0.50
0.21
C/W
C/W
Safe Operating Area Specification
Characteristic Values
Symbol
SOA
Test Conditions
Min.
Typ.
Max.
VDS = 75V, ID = 2.86A, TC = 75°C, Tp = 5s
214
W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
80
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
320
1.4
trr
IRM
QRM
160
14
1.3
ns
A
μC
IF = 40A, -di/dt = 100A/s,
VR = 38V, VGS = 0V
Note 1. Pulse test, t 300s, duty cycle, d 2%.
