IXRP 15N120
IXRA 15N120
Advanced Technical Information
VCES = 1200 V
IC25 = 25 A
VCE(sat) = 2.5 V typ.
IGBT with Reverse
Blocking capability
IXRP 15N120
IXRA 15N120
C
TO-220
C (TAB)
G
G
G
C
C (TAB)
C
E
E
TO-263
E
G = Gate,
C = Collector,
E = Emitter,
TAB = Collector
Features
IGBT
• IGBT with NPT (non punch through)
structure
• reverse blocking capability
- function of series diode monolithically
integrated, no external series diode
required
Symbol
VCES
Conditions
Maximum Ratings
TVJ = 25°C to 150°C
Continuous
1200
20
V
V
VGES
IC25
IC90
TC = 25°C
TC = 90°C
25
15
A
A
- soft reverse recovery
• positive temperature coefficient of
saturation voltage
• Epoxy of TO-247 package meets
UL 94V-0
ICM
VCEK
VGE = 0/15 V; RG = 47 Ω; TVJ = 125°C
RBSOA; Clamped inductive load; L = 100 µH
30
600
A
V
SCSOA
Ptot
600 V
10 µs
Applications
TC = 25°C
300
W
Converters requiring reverse blocking
capability:
- current source inverters
- matrix converters
- bi-directional switches
- resonant converters
- induction heating
- auxiliary switches for soft switching
in the main current path
Symbol
VCE(sat)
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
min.
typ. max.
IC = 10 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
2.5 2.95
3.3
V
V
VGE(th)
ICES
IC = 1 mA; VGE = VCE
3
6
V
VCE = VCES;VGE = 0 V; TVJ = 25°C
TVJ = 125°C
50 µA
mA
1.0
36
IGES
VCE = 0 V; VGE
=
20 V
500 nA
nC
QGon
VCE = 120 V; VGE = 15 V; IC = 10 A
IXYS reserves the right to change limits, test conditions and dimensions.
© 2005 IXYS All rights reserved
1 - 3
