IXTA10N60P
IXTP10N60P
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
TO-263 Outline
(TJ = 25°C, Unless Otherwise Specified)
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
6
11
S
Ciss
Coss
Crss
1720
160
14
pF
pF
pF
td(on)
tr
td(off)
tf
23
27
65
21
ns
ns
ns
ns
Resistive Switching Time
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 10Ω (External)
Qg(on)
Qgs
32
12
10
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCH
0.62 °C/W
°C/W
TO-220
0.50
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min. Typ.
Max.
IS
VGS = 0V
10
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
30
TO-220 Outline
1.5
V
IF = 10A, VGS = 0V
500
ns
-di/dt = 100A/μs, VR = 100V
Notes: 1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
2. On through-hole packages, RDS(on) Kelvin test contact
location must be 5mm or less from the package body.
Pins: 1 - Gate
2 - Drain
3 - Source
