Bu s s m a n n
Bla d e -Typ e Fu s e s
3 2 Vo lt s DC, 2 0 t o 8 0 Am p s
MAX
Dim e ns iona l Da ta
±0.005∑
±0.3mm
All tolerances:
3300AA
BUSS
MAXI-FUSE
.350"
(8.9mm)
.850"
(21.6mm)
0.5"
(12.7mm)
.315"
(8.0mm)
Ca ta log Sym bol: MAX
Tim e -Curre nt Cha ra c te ris tic Curve s –Ave ra ge Me lt
Fa s t-Ac ting
AMPERE
RATING
Am pe re Ra ting: 20 to 80 Amperes
Volta ge Ra ting: 32 Volts DC (or less)
Inte rrupting Ra ting: 1,000 Amperes
100
Ele c tric a l Ra tings (Ca ta log Sym bol, Am p Ra ting, a nd Color)
MAX-20
MAX-30
MAX-40
MAX-50
Yellow
Green
Orange
Red
MAX-60
MAX-70
MAX-80
Blue
Tan
10
Neutral
She lf Ca rton Qua ntity a nd We ight
Fuse
Type
Fuse
Qty.
No. of
Boxes
Wgt.
(Lbs.)
Dimensions
(Inches)
Volume
(Cu. Ins.)
1
MAX
20
20 (1-in)
0.60
2.88 ≈ 4.125 ≈ 1.75
20.0
Re c om m e nde d Bus s m a nn Fus e holde rs
Blade-Type
HHX
Fuseholder w/Cover
Body Only
#6 Lead Wire;
MAX
HHX-B
HHX-C
20-60 Amps
5∑ Length
.1
Cover Only
.01
CURRENT IN AMPERES
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin
is intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change
design or construction of any products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information con-
tained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
Form No. MAX
Page 1 of 1
BIF Doc #2049
12-21-98
SB98107
Rev. A
