High IP3
MAX-19H
Active Mixer
Level 0 (LO Power +0 dBm) 1700 to 1940 MHz
Maximum Ratings
OperatingTemperature
StorageTemperature
LO Power
Features
• low LO power, 0 dBm
• gain, 9 dB typ.
-40°C to 85°C
-55°C to 100°C
10 dBm
CASESTYLE:BJ937
PRICE: $19.95 ea. QTY (10)
• output IP3, 32 dBm typ.
• noise figure, 9 dB typ.
• patent pending
RFPower
15 dBm
DC Voltage
+5.5V
Applications
• GSM
• DCS/PCS
Pin Connections
LO
1
RF
3
Electrical Specifications (TAMB=25°C)
IF
5
7
RF
DC
FREQUENCY
(MHz)
OUTPUT
IP3
(dBm)
CONVERSION NOISE
LO-RF
ISOL.
(dB)
LO-IF*
ISOL.
(dB)
DC
POWER
Current
INPUT
@ 1dB
compr.
(dBm)
GAIN
(dB)
FIGURE
(dB)
GROUND
2,4,6,8
(mA)
Max.
Volt
Nom.
RF
LO
IF
Typ.
Min. Max.
Max.
Typ. Min.
Typ. Min.
OutlineDrawing
1700-1940 1450-1675 240-260
32
7
7.5
10
11
19 10
6
—
5
165
*LO to IF isolation is measured at input to LO internal amplifier and at output of internal IF amplifier.
To improve rejection, select filter from LFCN or HFCN series.
Typical Performance Data
Frequency
Conversion
Gain
L-R
Isolation
(dB)
Output
IP3
(dBm)
RF
MHz
LO
MHz
(dB)
1700.00
1755.00
1810.00
1865.00
1920.00
1947.00
1450.00
1506.25
1562.50
1618.75
1675.00
1703.00
9.09
8.95
9.06
9.12
9.12
9.19
22.27
22.82
21.61
26.59
28.07
28.28
30.44
32.23
32.47
31.66
30.89
30.31
MAX-19H
CONVERSION GAIN
MAX-19H
L-R ISOLATION
30
25
20
15
10
5
10.0
9.5
9.0
8.5
8.0
inch
Outline Dimensions (
)
mm
A
.395
B
.520
10.03 13.21
C
--
--
D
.100
2.54
E
.230
5.84
F
.110
2.79
G
.100
2.54
H
.047
1.19
J
.065
1.65
K
.065
1.65 10.80
L
.425
wt
0
grams
0.85
1700
1750
1800
1850
1900
1950
1700
1750
1800
1850
1900
1950
FREQUENCY (MHz)
FREQUENCY (MHz)
electrical schematic
MAX-19H
OUTPUT IP3
40
35
30
25
20
15
10
RF
LO
IF
+5V
1700
1750
1800
1850
1900
1950
FREQUENCY (MHz)
®
REV.
B
INTERNET http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
M102806
ED-10493A/1
MAX-19H
DJ/RS/CP
060223
