DX48HS

型号:

DX48HS

描述:

SMT半间距型无卤DIP开关[ SMT Half Pitch Type Halogen-Free DIP Switches ]

品牌:

GREATECS[ GREATECS ]

页数:

5 页

PDF大小:

182 K

DIP Switches
SMT Half Pitch Type Halogen-Free DIP Switches
DX48H Series
DX48HL...
Terminal Length 8.1mm
PCB LAYOUT
02
04
06
08
10
CODE OF
2
DX48HS...
Terminal Length 6.7mm
PCB LAYOUT
How to order:
Material:
1
2
3
4
5
Item Description Materials
Treatment
DX48H
1
Cover
High-Temp.
Thermoplastic
LCP
High-Temp.
Thermoplastic
LCP
Molded Black
Molded White
1
3
TERMINAL LENGTH:
8.1 mm
6.7 mm
5
ACTUATOR POSITION:
In OFF Position (Standard)
In ON Position
PACKAGE STYLE:
2
Actuator
TB Tube
TR Tape & Reel
L
S
F
O
3
4
5
Contact
Terminal
Base
Phosphor Bronze Gold Plated
Brass
Gold Plated
2
NO. OF POSITIONS:
4
N
T
SEAL:
Regular (Standard)
Top Tape Sealed
High-Temp.
Thermoplastic
LCP
02 2 Positions
04 4 Positions
06 6 Positions
08 8 Positions
10 10 Positions
Molded Black
Note:
6
Tape
Katpon
Br < 900 ppm
Cl < 900 ppm
Br+Cl < 1500 ppm
> General Tolerance: +/-0.2mm
> Unit in mm and inch (bracketed)
sales@greatecs.com
www.greatecs.com
1
DIP Switches
SMT Half Pitch Type Halogen-Free DIP Switches
DX48H Series
SPECIFICATIONS
1. Style:
This specification describes "SMT HALF PITCH TYPE DIP SWITCHES”
mainly used as signal switch of electric devices, with the general
requirements of mechanical and electrical characteristics.
1.1 Operating Temperature Range : -40ɗ~+85ɗ
1.2 Storage Temperature Range :-40ɗ~+85ɗ
2. Current Range:
2.1 Non-Switching: 100mA, 50V DC
2.2 Switching: 25mA, 24V DC
3. Type of Actuation: Actuated by sliding
4. Test Sequence:
ITEM DESCRIPTION
TEST CONDITIONS
REQUIREMENTS
There shall be no
Visual
By visual examination check without defects that affect the
1.
Examination any out pressure & testing.
serviceability of the
product.
1)To be measured between the two
terminals associated with each
switch pole.
Contact
2.
100mŸ max. (initial)
Resistance
2)Measurements shall be made with
a 1 kHz shall current contact
resistance meter.
Insulation
3.
500 V DC , 1 minute 5 sec.
100MŸ min
Resistance
300 V AC (50Hz or 60 Hz) shall be
applied between all the adjacent
Dielectric
4. withstanding
Voltage
There shall be no
terminals and between the terminal breakdown or flashover.
and the frame for 1 minute.
5. Capacitance
1MHz 10kHz
5 pF max.
sales@greatecs.com
www.greatecs.com
2
DIP Switches
SMT Half Pitch Type Halogen-Free DIP Switches
DX48H Series
Applied in the direction of operation.
ON OFF
OFF ON
30°~120°
500 gf max
Operation
Force
6
7
4.9N max㸧
1 kgf is applied in the operating direction
and pulling direction operated for a
period of 15 seconds.
Stop
Strength
There shall be no sign of
damage mechanically.
1)Soldering Temperature :
PROD
SMT TYPE TERMINAL
SERIES
1)As shown in item 3~6
2)Contact Resistance: 2Ÿ
max.
TEMP
TIME
260 5ɗ
5~10sce
Soldering
Heat
Resistance
8
2)Duration of Solder Immersion:
(final-after test)
5 1seconds.
3)Frequency of Solder Process:
1 times max.
(PCB is 1.6 mm in thickness.)
Shall be vibrated in accordance with
Method 201A of MIL-STD-202F
1)Frequency: 10-55-10 Hz 1 min/cycle.
2)Direction: 3 vertical directions
including the direction of operation
3)Test Time: 2 hours each direction.
Shall be shocked in accordance with
Method 213B Condition A of MIL-STD-
202F
1)As shown in item 2~6
2)Contact Resistance: 2Ÿ
max.)
9 Vibration
(final-after test)
1)As shown in item 2~6
2)Contact Resistance: 2Ÿ
max.
10 Shock
1)Acceleration : 50G
2)Action Time : 11 1 m seconds
3)Testing Direction : 6 sides
4)Test cycle : 3 times in each direction
(final-after test)
sales@greatecs.com
www.greatecs.com
3
DIP Switches
SMT Half Pitch Type Halogen-Free DIP Switches
DX48H Series
Measurements shall be made
following
1)As shown in item
the test set forth below:
3,4
1)25mA,24 V DC resistive load
11 Operation Life
2)Contact Resistance:
2Ÿ max.
(final-after test)
2)Rate of Operation : 15~20
cycles/minute
3)Cycle of Operation :
1000 cycles
Following the test set forth below the
sample shall be left in normal
1)As shown in item
2~6
temperature and humidity conditions
Resistance Low
12
13
for an hour before measurements are 2)Contact Resistance:
Temperature
made :
2Ÿ max.
(final-after test)
1)Temperature : -40 3ɗ
2)Time : 96 hours
Following the test set forth below the
1)As shown in item
3~6
sample shall be left in normal
Resistance High temperature and humidity conditions for
2)Contact Resistance :
2Ÿmax.
an hour before measurements are made :
1)Temperature :85 2ɗ
Temperature
(final-after test)
2)Time : 96 hours
1)As shown in item
4~6
Following the test set forth below the
sample shall be left in normal
temperature and humidity conditions for
an hour before measurements are made :
1)Temperature : 40 2ɗ
2)Relative Humidity : 90~95%
3)Time : 96 hours
2)Contact Resistance :
2Ÿmax.
Resistance
Humidity
14
3)Insulation
Resistance:
10 MŸ min .
sales@greatecs.com
www.greatecs.com
4
DIP Switches
SMT Half Pitch Type Halogen-Free DIP Switches
DX48H Series
5. SOLDERING CONDITIONS:
Condition for Soldering
MAX
260°
255°
230°
150°
Room
Temperature
5~10sec
120~150sec
60sec
TIME(sec)
The condition mentioned above is the temperature on the Cu foil of the PCB surface.
There are cases where board's temperature greatly differs from switch's surface
temperature depending on board's material, size, thickness, etc. Care, therefore,
should be used not to allow switch's surface temperature to exceed 260ɗ.
Manual Soldering
Soldering Temperature
Max,350ɗ
Continuous Soldering Time
Max,5 seconds
Precautions in Handling
1. Care should be exercised so that flux from the upper part of the printed circuit board
does not adhere to the switch.
2. Don’t clean the switch body except with top tape sealed type, which can only spray of
cleaning method from top of s/w.
3. Slide the DX48 actuator from Z axial direction with in 30°~120°of max 300 gf / 10
30°~12
sec operation.
4. The suggest tool for actuator adjust is as below. ( example for 4 position )
sales@greatecs.com
www.greatecs.com
5
