IXTA170N075T2
IXTP170N075T2
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
TO-263 (IXTA) Outline
(TJ = 25°C, unless otherwise specified)
gfs
VDS = 10V, ID = 60A, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
40
70
S
Ciss
Coss
Crss
6860
810
pF
pF
pF
148
td(on)
tr
td(off)
tf
19
11
25
19
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 3.3Ω (External)
Qg(on)
Qgs
109
37
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
25
RthJC
RthCH
0.42 °C/W
°C/W
TO-220
0.50
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min. Typ.
Max.
170
680
1.0
IS
VGS = 0V
A
A
V
ISM
VSD
Repetitive, Pulse width limited by TJM
IF = 50A, VGS = 0V, Note 1
TO-220 (IXTP) Outline
trr
63
4.8
ns
A
IF = 85A, VGS = 0V
IRM
QRM
-di/dt = 100A/μs
VR = 37V
150
nC
Notes: 1. Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
2. On through-hole packages, RDS(on) Kelvin test contact
location must be 5mm or less from the package body.
Pins: 1 - Gate
3 - Source
2 - Drain
4 - Drain
PRELIMINARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from data gathered during objective characterizations of preliminary engineering lots; but also may yet
contain some information supplied during a pre-production design evaluation. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS reserves the right to change limits, test conditions, and dimensions.
