IXTA14N60P IXTP14N60P
IXTQ14N60P
Symbol
Test Conditions
Characteristic Values
TO-3P (IXTQ) Outline
(TJ = 25°C, unless otherwise specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
7
13
S
Ciss
Coss
Crss
2500
215
13
pF
pF
pF
td(on)
tr
td(off)
tf
23
27
70
26
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 10Ω (External)
Qg(on)
Qgs
36
16
12
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
0.42 °C/W
(TO-220)
(TO-3P
0.50
0.25
°C/W
°C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Min.
Typ.
Max.
IS
VGS = 0V
14
A
A
ISM
VSD
trr
Repetitive, pulse width limited by TJM
IF = IS, VGS = 0V, Note 1
42
1.5
V
TO-220 (IXTP) Outline
IF = 14A, -di/dt = 100A/μs
500
ns
VR = 100V, VGS = 0V
Note 1: Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
TO-263 (IXTA) Outline
Pins: 1 - Gate
3 - Source
2 - Drain
4 - Drain
