XVT9011
• Voltage Controlled Temperature Compensated Crystal Oscillator
• Excellent Frequency Stability & Low Phase Noise
• 3.2 x 2.5 x 1.2 mm Surface-mount Case
13.000000
MHz
• Complies with Directive 2002/95/EC (RoHS)
Pb
SM3225-4 Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
Nominal Frequency
fo
13.000000
MHz
°C
Component Storage Temperature Range
Storage Temperature Range in Tape and Reel
Soldering Profile, 10 seconds, up to 5 cycles
Operating Temperature Range
Power Supply Voltage
-30
-30
+85
+85
260
+70
3.46
°C
°C
-20
3.14
0.8
°C
Vcc
3.30
V
VP-P
Output Voltage with Load 10 pF||10 K
Vout
Output Waveform
clipped sinewave
Power Supply Current
Icc
2.0
2.5
mA
V
Control Voltage
Vcon
0.5
Control Voltage Input Impedance
Frequency Tolerance, Single Solder Reflow, Vcontrol = 1.50 V
Frequency Stability versus:
100K
ohms
±2.0 ppm max @ 25 °C ±2 °C
Temperature, -20 to 70 °C
±0.5
±0.2
±0.2
ppm
ppm
Supply Voltage, 3.14 to 3.46 V
Load 10 pF||10 K±10%
ppm
Control Voltage Frequency Range, 0.5 to 2.5 V
Start Up Time, 90% of final RF level in VP-P
±3
±7
ppm/V
ms
5.0
Aging @ 25 °C
±1
ppm/year
dBc
Harmonics
-5.0
SSB Phase Noise @ 1 kHz Carrier Offset
Lid Symbolization
-130
dBc/Hz
9011/YWWS
