IXER35N120D1_06

型号：

IXER35N120D1_06

描述：

NPT3 IGBT与二极管ISOPLUS247[ NPT3 IGBT with Diode in ISOPLUS247 ]

品牌：

IXYS[ IXYS CORPORATION ]

页数：

4 页

PDF大小：

152 K

下载PDF手册
IXER 35N120D1
NPT3 IGBT
IC25
VCES
= 50A
=1200V
with Diode
in ISOPLUS247TM
VCE(sat)typ. = 2.2V
ISOPLUS 247TM
E153432
C
E
G
G
C
E
Isolated Backside
C = Collector E = Emitter
G = Gate
Ftures
IGBT
• NPTIGBT
- low saturation voltage
- positive temperature coefficient for
easy paralleling
- fast switching
Symbol
VCES
Conditions
Maximum Ratings
TVJ = 25°C to 150°C
1200
20
V
VGES
- short tail current for optimized
performance in resonant circuits
• HiPerFREDTM diode
IC25
IC90
TC = 25°C
TC = 90°C
50
32
A
A
ICM
VCEK
VGE = 15 V; RG = 39 Ω; TVJ = 125°C
RBSOA, Clamped inductive load; L = 100 µH
50
VCES
A
µs
W
- fast reverse recovery
- low operating forward voltage
- low leakage current
tSC
(SCSOA)
VCE = 900V; VGE = 15 V; RG = 39 Ω; TVJ = 125°C
non-repetitive
10
• ISOPLUS 247TM package
- isolated back surface
- low coupling capacity between pins
and heatsink
Ptot
TC = 25°C
200
- high reliability
- industry standard outline
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
Applications
min.
typ. max.
• single switches
• choppers with complementary free
wheeling diodes
• phaselegs, H bridges, three phase
bridges e.g. for
- power supplies, UPS
- AC, DC and SR drives
- induction heating
VCE(sat)
IC = 35 A; VGE = 1V; TVJ = 25°C
TVJ = 125°C
2.2
2.6
2.8
V
V
VGE(th)
ICES
IC = 1 mA; VGE = VCE
4.5
6.5
V
VCE = VCES;VGE = 0 V; TVJ = 25°C
TVJ = 125°C
0.4 mA
mA
0.4
IGES
VCE = 0 V; VGE
=
20 V
200 nA
td(on)
tr
td(off)
tf
Eon
Eoff
85
50
440
50
5.4
2.6
ns
ns
ns
ns
mJ
mJ
Inductive load, TVJ = 125°C
VCE = 600 V; IC = 35 A
VGE = 15 V; RG = 39 Ω
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 600 V; VGE = 15 V; IC = 35 A
2
150
nF
nC
RthJC
RthCH
0.6 K/W
K/W
with heatsink compound
0.3
© 2006 IXYS All rights reserved
1 - 4
IXER 35N120D1
Diode
Equivalent Circuits for Simulation
Conduction
Symbol
Conditions
Maximum Ratings
IF25
IF90
TC = 25°C
TC = 90°C
48
25
A
A
IGBT (typ. at VGE = 15 V; TJ = 125°C)
Symbol
VF
Conditions
Characteristic Values
min. typ. max.
V0 = 0.95 V; R0 = 45 mΩ
IF = 35 A; TVJ = 25°C
TVJ = 125°C
2.5
1.9
2.9
V
V
Diode (typ. at TJ = 125°C)
V0 = 1.26V; R0 = 15 mΩ
IRM
trr
51
80
A
ns
Thermal Response
IF = 30 A; di /dt = -1100 A/µs; TVJ = 125°C
VR = 600 V;FVGE = 0 V
Erec(off)
1.8
mJ
RthJC
RthCH
1.2 K/W
K/W
with heatsink compound
0.6
IGB
Cth1 = 0.067 J/K; Rth1 = 0.108 K/W
Cth2 = 0.175 J/K; Rth2 = 0.491 K/W
Component
Symbol
Diode
Cth1 = 0.039 J/K; Rth1 = 0.311 K/W
Cth2 = 0.090 J/K; Rth2 = 0.889 K/W
Conditions
Maximum Rngs
TVJ
Tstg
-55...+150
-55...+125
°C
°C
ISOPLUS247TM OUTLINE
VISOL
FC
IISOL ≤ 1 mA; 50/60 Hz
2500
V~
N
mounting force with clip
0...120
Symbol
Cp
Conditions
Characteristic Values
min.
typ. max.
coupling capacity between shorted
pins and mounting tab in he case
30
pF
g
Weight
6
The convex bow of substrate is typ. < 0.04 mm over plastic surface level
of device bottom side
This drawing will meet all dimensions requirement of JEDEC outline
TO-247 AD except screw hole and except Lmax.
© 2006 IXYS All rights reserved
2 - 4
IXER 35N120D1
120
A
100
120
A
100
VGE = 17 V
VGE = 17 V
15 V
15 V
13 V
IC
IC
13 V
11 V
80
60
40
20
0
80
60
40
20
0
11 V
9 V
9 V
TVJ = 125°C
TVJ = 25°C
V
V
6 7
0
1
2
3
4
5
6
7
0
1
2
3
4
5
VCE
VCE
Fig. 1 Typ. output characteristics
Fig. 2 Typ. output characteristics
90
A
120
A
VCE = 20 V
75
IF
100
IC
60
80
60
40
20
0
45
TVJ = 125°C
TVJ = 25°C
30
15
0
TVJ = 125°C
TVJ = 25°C
10
V
0
1
2
3
4
4
6
8
12
VG
14 V 16
VF
Fig. 3 Typ. transfer characristi
Fig. 4 Typ. forward characteristics of
freewheelingdiode
20
10
K/W
1
V
diode
15
ZthJC
IGBT
VGE
0.1
10
5
0.01
0.001
single pulse
0.1
VCE = 600 V
IC = 35 A
MUBW3512E7
0
0.0001
0
40
80
120
160nC 200
QG
0.001
0.01
1
10
s
t
Fig. 5 Typ. turn on gate charge
Fig. 6 Typ. transient thermal impedance
© 2006 IXYS All rights reserved
3 - 4
IXER 35N120D1
20
100
ns
6
mJ
4
1200
ns
VCE = 600 V
VGE 15 V
t
d(on)
mJ
16
Eoff
=
1000
80
70
60
50
40
30
20
10
0
RG = 39 Ω
TVJ = 125°C
Eoff
Eon
t
t
800
600
400
200
0
12
8
t
r
VCE = 600 V
VGE 15 V
=
td(off)
E
on
2
0
RG = 39 Ω
TVJ = 125°C
4
Erec(off)
tf
0
A
A
0
20
40
60
80
0
20
40
60
80
IC
IC
Fig. 7
Typ. turn on energy and switching
times versus collector current
Fig. 8
Typ. turn off energy and switching
times versus collector current
8
mJ
6
160
4
800
ns
VCE = 600 V
VCE = 600 V
VGE 15 V
mJ
VG
15 V
ns
=
E
on
IC = 5 A
TVJ = 125°C
IC = 35 A
TVJ = 125°C
Eoff
Eon
120
3
2
1
0
600
400
200
0
t
t
t
Eff
d(on)
4
2
0
80
40
0
td(off)
t
r
EREC(off)
tf
Ω
80
10
20
30
40
50
60
RG
70 Ω 80
10
20
30
40
50
60
70
RG
Fig. 9 Typ. turn on energy and switching
times versus gate retor
Fig.10 Typ. turn off energy and switching
times versus gate resistor
12
70
60
50
40
30
20
10
0
350
300
250
200
150
100
50
TVJ = 125°C
15Ω
I=30 A
RG
39
=
15
Ω
TVJ = 125°C
VR = 600 V
IRM
24
Ω
70A
24Ω
10
8
F
39Ω
VR = 600 V
Ω
56
Ω
56Ω
50A
75
Ω
RG=
75Ω
75Ω
35A
6
tRR
56Ω
Ω
39
24Ω
15Ω
IF=
15A
4
7,5A
2
0
0
0
200
400
600
800
1000
1200
1400
1600
1800
0
200
400
600
800
1000
1200
1400
1600
1800
-diF/dt [A/µs]
-diF/dt [A/µs]
Fig. 11 Typ. turn off characteristics
of free wheeling diode
Fig. 12 Typ. turn off characteristics
of free wheeling diode
© 2006 IXYS All rights reserved
4 - 4
