Application:
The SafeSite® Series LED area light represents the future of energy
efficient facility illumination for hazardous locations worldwide. The Class
I, Div 1 LED area lighting fixture consumes at least 50% energy compared
to traditional HID light sources, while reducing maintenance and carbon
emissions. This light incorporates both cutting edge LED technology
along with proprietary optics to achieve area lighting comparable with
other traditional light sources.
Whether your application is in a refinery, oil platform, chemical plant or
any other Class I, Division 1 application, this fixture offers improved
performance across the board.
Patent Pending
SafeSite® Series LED Area Light
Mechanical Information
Fixture Weight:
Mounting:
14.5 lb (6.58 kg)
10.7
[272]
6.0
(1) Threaded 3/4” NPT rear
[152]
Electrical specifications
Operating Voltage:
2.0
9.7
[246]
[51]
100-277VAC, 50/60 Hz
70W
Ø.213
[5,41]
Power Consumption:
5.8
[148]
°
°
°
°
Operating Temp:
Harmonics:
-40 F to +149 F (-40 C to +65 C)
IEC 61000-3-2
Surge / Lightning
Protection:
1 kV line to line
2 kV line to ground
Ø.197
[5]
Dimensions in Inches [mm]
THD:
< 15%
> 0.95
Certifications & Ratings:
w Class I, Div 1, Groups C, D
w Class II, Div 1, Groups E, F, G
w UL 844
w CSA 22.2 No. 137-M1981
w IP66 (pending)
Power Factor:
Power supply equipped with inline fuse
Construction:
w NEMA 4X (pending)
Body:
Finish:
Powder Coated Aluminum
Features & Benefits:
w 5 year warranty
w 70% lumen maintenance over 60,000 operating hours
w Low power consumption
w Maintenance free
Polyester / epoxy powder coat grey
Standard RAL 7040
Lens:
Glass
w Instant on/off operation
Photometric Information
CRI (nom):
w Universal input (100-277 VAC), 50/60Hz
w Superior color rendition index compared to HPS, LPS, MV
w Mercury free
> 70
w No UV or IR
w Resistant to shock and vibration
w Temperature compensation technology for longer life
CCT (nom):
6,000K (cool white)
4,500K (neutral white)
Optics:
180° forward throw
Available upon request
Temperature Ratings
IES Files:
Ambient Temperature Range
T4a Temperature Code
Ambient Temperature Range
T5 Temperature Code
-40F to +149F (-40C to +65C)
-40F to +113F (-40C to +45C)
Ordering Codes:
Part Number
HZC8C2N
Lumens
5,500
Lumens Per Watt
Color
79
79
Cool White
Neutral White
HZC8N2N
5,500
www.dialight.com
