Application:
Dialight introduces the new state of the art fixture for hazardous location
lighting. Its rugged solid state design creates a new era where failed
lamps and expensive relamping costs become a thing of the past. This
light incorporates both cutting edge LED technology along with
proprietary optics to achieve area lighting comparable with other
traditional light sources. By focusing the light where it is needed, the
SafeSite Series is the most efficient light source available for hazardous
area lighting applications. Whether your application is in a refinery, oil
platform, chemical plant or any other Class I, Division 2 / Class II, Div 2
application, this fixture offers improved performance across the board.
Patents Pending
®
SafeSite LED Area Light
Mechanical Information:
Container Dimensions: 15” X 16” X 10”
381mm x 407mm x 254mm
Container Weight:
Mounting:
19 lbs (8.2 kg)
Mtg. Hole
Threaded 1” NPT on 3 sides of splice box
Electrical specifications:
Operating Voltage:
120-277 VAC, 50/60 Hz
(DC versions available - consult factory)
Power Consumption:
Operating Temp:
Harmonics:
70 W (70 Series), 100w (150 &250) Series
-40ºF to +133ºF (-40ºC to +55ºC)
IEC 6100-3-2
Surge / Lightning
Protection:
1 kV line to line
2 kV line to ground
Dimensions in Inches [mm]
Certifications & Ratings:
THD:
<5% (120VAC)
<10% (230/240VAC)
<15% (277VAC)
w Class I, Div 2, Groups A, B, C, D hazardous environments T4A rated
w Class II, Div 2, Groups F, G hazardous environments T3B rated
w Certified to UL844 / NEMA 4X / UL1598 / UL1598A / CSA 22.2
w IP66 rated
Power Factor:
Material:
Lens:
> 0.9
Features & Benefits:
w Low power consumption
w Instant on/off response
w Weather/corrosion resistant lamp assembly and housing
w Universal input (120-277 VAC), 50/60 Hz
w *Resistant to shock (IEC 68-2-27) and vibration (FAA 150/5345-46C)
w 5 year warranty
UV stabilized Polycarbonate with enhanced
abrasive resistance
Body:
Grey powder coated aluminum
Grey powder coated aluminum
Heat sink:
w 70% lumen maintenance over 60,000 operating hours
Accessories (hardware): Stainless steel
Order Codes:
Photometric Information:
SafeSite 70 Series
HZC020701111212 CID2/CIID2 Cert - 180 Degree
HZC020701111312 CID2/CIID2 Cert - 360 Degree
CRI (typ):
CCT:
70
4500-7000K
SafeSite 150 Series
HZC021501111212 CID2/CIID2 Cert - 180 Degree
HZC021501111312 CID2/CIID2 Cert - 360 Degree
SafeSite 250 Series
HZC022501111212 CID2/CIID2 Cert - 180 Degree
HZC022501111312 CID2/CIID2 Cert - 360 Degree
1
