C-Band
SPECIFICATIONS, VZC-6967V7
Electrical
Electrical (continued)
Frequency
5.850-6.650 GHz
Group Delay
0.0± nsꢀMHz linear max.
(in any ꢁ0 MHz band)
0.00± nsꢀMHz sq. parabolic max.
0.5 ns pk-pk ripple max.
Output Power
TWT
Flange
750 W min.
650 W min.
Primary Power
Voltage
Frequency
Single pꢂase, 200-2ꢁ0 VAꢃ ±±0ꢄ
ꢁ7- 63 Hz
Bandwidth
Gain
800 MHz
O P T I O N S :
70 dB min. at rated power
75 dB min. at small signal
• Integral Linearizer
• Remote Control Panel
Power Consumption
2.3 kVA typ.
RF Level Adjust Range
20 dB min. (via PIN diode attenuator)
(at saturated RF output power)
2.6 kVA max.
• Redundant and Power
Combined Subsystems
Gain Stability
At constant drive & temp.
±0.25 dBꢀ2ꢁ ꢂrs. max.
(after 30 min. warmup)
±±.0 dB over oper. temp. range
±0.75 dB over ±±01ꢃ
Power Factor
95 min.
• Extended Frequencies
(5.850 to 7.100 GHz:
Model Number
VZC-6967VE; 5.850
to 6.725 GHz: Model
Number VZC-6967VB;
Model VZC-6967VA:
5.725 to 6.650 GHz)
Inrush Current
200ꢄ max.
Over temp., constant drive,
(any frequency)
Environmental
Ambient Temperature
-ꢁ0° to + 55°ꢃ operating,
including solar loading
(+60°ꢃ optional);
Small Signal Gain Slope
±0.02 dBꢀMHz max.
Small Signal Gain Variation
Across any ꢁ0 MHz band
Across tꢂe 800 MHz band
0.5 dB pk-pk max.
2.5 dB pk-pk max.
-ꢁ0° to + 75°ꢃ non-operating
Relative Humidity
Altitude
±00ꢄ condensing
Input VSWR
±.3:± max.
±.3:± max.
±0,000 ft. witꢂ standard adiabatic
derating of 2°ꢃꢀ±000 ft., operating;
50,000 ft. non-operating
• External Receive Band
Reject Filter (increases loss
by a minimum of 70 dB
up to 4.8 GHz)
Output VSWR
Load VSWR
ꢃontinuous operation
Full spec compliance
Operation witꢂout damage
2.0:±
±.5:±
Any value
Shock and Vibration
Designed for normal transportation
environment per Section 5±ꢁ.ꢁ
MIL-STD-8±0E. Designed to
witꢂstand 20G at ±± ms (±ꢀ2 sine
pulse) in non-operating condition.
Residual AM, max
-50 dBc below ±0 kHz
-20 (±.5 + log F kHz) dBc,
±0 kHz to 500 kHz
Acoustic Noise
Mechanical
Cooling
68 dBA (as measured at 3 ft.)
-85 dBc above 500 kHz
Phase Noise
IESS-308ꢀ309
pꢂase noise continuous
Aꢃ fundamentals related
Sum of spurs (370 Hz to ± MHz) -ꢁ7 dBc
±2 dB below mask
-36 dBc
Forced air wꢀ integral blower.
RF Output Connection
ꢃPR-±37 waveguide flange,
grooved, tꢂreaded UNF 2B ±0-32
RF Output Monitor
Type N female
AM/PM Conversion
2.5°ꢀdB max. for a single-carrier
at 8 dB below rated power
(at 3 dB backoff witꢂ optional linearizer)
Dimensions (WxHxD)
±ꢁ.5 x ±3.± x 2ꢁ in.
(368 x 333 x 6±0)
Weight
87 lbs (39.5 kg) max.
Harmonic Output
-60 dBc at rated power,
second and tꢂird ꢂarmonics
Heat Dissipation
Into Hub
Noise and Spurious
<-±50 dBWꢀꢁ kHz, 3.ꢁ to ꢁ.2 GHz
<-65 dBWꢀꢁ kHz, ꢁ.2 to ±2.0 GHz
(<-60 dBWꢀꢁ kHz wꢀ optional linearizer)
<-±±0 dBWꢀꢁ kHz, ±2.0 to ꢁ0.0 GHz
200 W
Ducted
2000 W
Intermodulation
-2ꢁ dBc max. witꢂ two equal carriers
at total output power 7 dB (3 dB witꢂ
optional integral linearizer) below rated
single-carrier output
Certificate Number: 30515
For more detailed information, please refer to the corresponding CPI Technical Description.
Note: Specifications may change without notice as a result of additional data or product refinement. Please
contact CPI before using this information for system design.
