VWO 36
Three Phase
AC Controller Modules
IRMS = 3x 39 A
VRRM = 800-1600 V
Preliminary data
14
1
7
16
2
8
17
3
9
VRSM
VDSM
VRRM
VDRM
Type
V
V
800
1200
1400
1600
800
1200
1400
1600
VWO 36-08io7
VWO 36-12io7
VWO 36-14io7
VWO 36-16io7
10
11
13
Symbol
Test Conditions
Maximum Ratings
Features
IRMS
ITRMS
ITAVM
TK = 85°C, 50 - 400 Hz (per phase)
TVJ = TVJM
TK = 85°C; (180° sine)
39
28
18
A
A
A
• Thyristor controller for AC (circuit
W3C acc. to IEC) for mains requency
• Package with metal base plate
• Isolation voltage 3000 V~
• Planar passivated chips
ITSM
TVJ = 45°C;
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
320
350
A
A
• UL applied
• ¼" fast-on power terminals
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
280
310
A
A
I2t
TVJ = 45°C
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
500
520
A2s
A2s
Applications
T
VJ = TVJM
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
390
400
A2s
A2s
• Switching and control of
three phase AC circuits
• Softstart AC motor controller
• Solid state switches
VR = 0
(di/dt)cr
TVJ = TVJM
repetitive, IT = 20 A
150
A/ms
f =50 Hz, tP =200 ms
VD = 2/3 VDRM
IG = 0.3 A
• Light and temperature control
non repetitive, IT = ITAVM
VDR = 2/3 VDRM
500
A/ms
V/ms
diG/dt = 0.3 A/ms
Advantages
(dv/dt)cr
PGM
TVJ = TVJM
;
1000
R
GK = ¥; method 1 (linear voltage rise)
• Easy to mount with two screws
• Space and weight savings
• Improved temperature and power
cycling capability
• High power density
• Light weight and compact
TVJ = TVJM
IT = ITAVM
tp = 30 ms
tp = 300 ms
10
5
W
W
W
PGAVM
VRGM
0.5
10
V
TVJ
TVJM
Tstg
-40...+125
125
-40...+125
°C
°C
°C
VISOL
50/60 Hz, RMS
t = 1 min
t = 1 s
2500
3000
V~
V~
IISOL £ 1 mA
Md
Mounting torque (M5)
5 ± 15 %
Nm
(10-32 UNF)
44 ± 15 %
lb.in.
Weight
typ.
110
g
Data according to IEC 60747 refer to a single thyristor/diode unless otherwise stated.
IXYS reserves the right to change limits, test conditions and dimensions
© 2000 IXYS All rights reserved
1 - 2
