Performance Speci!cations
Parameter
Min Typ Max
Units
Condition
Frequency Tuning (EFC)
-60
0.0
+60
10
ppm
ꢀ
Tuning Range
Linearity
Positive
5.0
Tuning Slope
2.5
VDC
Control Voltage Range
Additional Parameters
Swept quartz, AT, 3 point mount
Crystal:
Components:
Rework:
Class “S”Microelectronic element evaluation per Appendix B of MIL-PRF-55310D
In accordance with MIL-PRF-55310D, Class S
In accordance with MIL-PRF-55310D, Table III, including internal visual inspection per
MIL-STD-883, Method 2017, and PIND testing
Class “S”screened:
100ꢀ PIND testing:
In accordance with MIL-STD-883, Method 2020, Condition B. We may use a VI
approved material as a “getter”in our manufacturing process to help pass PIND.
Group A & B:
Salt Spray:
100ꢀ Group A and 100ꢀ Group B testing
Salt spray/salt atmosphere not included in this speci#cation.
Shock: 100G, 6 ms per MIL-STD-202, Method 213, Condition C
Vibration: Sine: 20G to 2 kHz per MIL-STD-202, Method 204, Condition D
Random: 20 Grms overall to 2 kHz per MIL-STD-202, Method 214, Condition I-F
Standard shock and vibration
(survive; met by design, not tested):
Notes:
1.
2.
Active parts are of bi-polar technology and, therefore, are inherently radiation tolerant. If
required, VI will provide a parts list and schematic (NDA required) for review and approval
of radiation hardness.
Engineering models are #t, form and function representative of Flight Models and of
commercial construction using commercial parts of same generic type as Flight Models.
Completed oscillators are not screened, will not contain swept quartz, and are not suitable
for $ight, DPA, or RGA. Engineering models will not be processed to pass PIND.
