Ordering Information
VX-401 0 - E A E - 305 0 - 122M880 - 153M600
Model Code
Frequency 2
Frequency 1
Height
0: 5.9 mm (G223B)
Enable
0: No Enable
1: Enable
Supply Voltage
D: 5V
E: 3.3V
Stability Code
E-305: ±30ppm
Temperature Range
E: -40°C to +85°C
RF Output Code
C: PECL
D: LVDS
Notes:
1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all
frequencies.
2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency
control voltage, load, temperature (25°C).
3. Phase noise degrades with increasing output frequency.
4. Subject to technical modification.
5. Contact factory for availability.
For Additional Information, Please Contact
USA:
Europe:
Asia:
Vectron International
267 Lowell Road
Hudson, NH 03051
Tel: 1.888.328.7661
Vectron International
Landstrasse, D-74924
Neckarbischofsheim, Germany
Tel: +49 (0) 7268-801-0
Vectron International
1F-2F, No 8 Workshop, No 308 Fenju Road
WaiGaoQiao Free Trade Zone
Pudong, Shanghai, China 200131
Tel: 86.21.5048.0777
Fax: 1.888.329.8328
Fax: +49 (0) 7268-801-281
Fax: 86.21.5048.1881
Disclaimer
Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application.
No rights under any patent accompany the sale of any such product(s) or information.
Rev: 10/2011
Page 6 of 5
