Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options
M Series
UL Recognized
CSA Certified
VDE Approved
XM / ZM
VM
Ordering Information
M Series
• Family of slim power entry modules that consume
minimal depth behind panel
5 E F M 4 S C
Mounting Type
C– Snap-In
• Four compact modules each provide a different
option combination
Omit for flange mount
• Available non-filtered or with one of four filter
circuits designed to meet a wide variety of
applications
3
Switch Option
S – DPST on/off switch
Omit for none
• Optional voltage selector configured for either
2 or 4 voltage selection
• Optional DPST on/off switch
Voltage Selection Positions
1 or 4
• Included fuseholder accepts either single 3AG fuse
or dual metric fuses
M Series
• Snap-in or flange mounting styles
Filter Type
F – General purpose
H – Medical
Filter Types
H Models provide a basic performance dual
element circuit EMI filter with minimal leakage
current, suitable for medical applications, with
attenuation similar to the EAH Series power inIet
filter.
X – High performance
Z – Premium performance
V – Non-filtered
Leakage current designation
E – Low leakage (<0.5 mA)
(Filtered models only)
F Models provide a basic performance dual
element circuit EMI filter, with attenuation similar
to the EEA Series Power Inlet Filter.
X Models provide a high performance three
element differential circuit filter, with extended
EMI attenuation similar to the X Series chassis
filter, suitable for bringing most digital equipment
(including switching power supplies) into compli-
ance with FCC Part 15J, Class B conducted
emissions limits.
Current Rating @120 VAC
3, 5 or 6A
Z Models provide a premium performance three
element differential circuit filter, with enhanced
EMI low frequency attenuation similar to the P
Series Z models, suitable for bringing most digital
equipment (including switching power supplies)
into compliance with EN55022 Level B as well as
FCC Part 15J. For minimum panel footprint, see
the P series on page 192.
183
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options (continued)
M Series
Specifications
Accessories
GA400
: NEMA 5-15P to IEC 60320-1 C-13 line cord
Maximum leakage current each Line to Ground:
HM
2 A
5 A
FM
.25 mA
.50 mA
XM/ZM
.30 mA
.50 mA
@ 120 VAC 60 Hz:
@250 VAC 50 Hz:
Hipot rating (one minute):
Line to Ground:
2250 VDC
1450 VDC
2500 VAC
Line to Line:
Line to Load (switch off) non-filtered:
Rated Voltage (max.):
250VAC
50/60 Hz
3 to 6A
MA100: Power interconnect assembly
Operating Frequency:
For voltage select models. 8.5” wire leads
Rated Current @ 120 VAC:
Rated Current @ 250 VAC:
3A models:
5A models:
6A Switched models:
6A non-switched models:
2A
4A
5A
6A
MA101
: Plug only
Required Fuse(s):
Reversible fuseholder accepts
one .25 x 1.25” (not included)
or two 5 x 20mm (not included)
MA102
: Strip of 100 pins for use with MA101
: Individual pins for use with MA101
MA104
Switch:
DPST
100,000 operations at 70A max. inrush
MA302: Two Voltage Selection Card
Marked 120V/240V. One card comes standard with
every 2 voltage M series module
MA304: Four Voltage Selection Card
Marked 100V/120V/230V/240V. One card comes
standard with every 4 voltage M series module
Available Part Numbers
Non-Filtered Models
3
2
Voltage
Selections
Flange Mount
Snap-In
1
2
4
6VM1
6VM2
6VM4
6VM1S
6VM2S
6VM4S
6VM1C 6VM1SC
6VM4C 6VM4SC
0
1
0
General Purpose Filters
1
4
5EFM1 5EFM1S 5EFM1C 5EFM1SC
5EFM4 5EFM4S 5EFM4C 5EFM4SC
Medical Filters
MA400
: Medical safety bracket assembly
Prevents inadvertent removal of fuse(s)
1
4
5EHM1 5EHM1S
5EHM4 5EHM4S
High Performance - FCC-B
1
4
3EXM1S
3EXM4 3EXM4S
MA401: Bracket only
MA402: Standoff only
Premium Performance - EN55022-B
1
3EZM1S
4
3EZM4 3EZM4S
184
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options (continued)
M Series
Accessories (continued)
Fuse Installation Instructions
MA601 - 604: Insulating Boot
Plastic shroud for back of M series to prevent
inadvertent access to connections
1. Remove power cord
2. Insert a pocket screwdriver at point “X” as shown
A
MA601
: Fits M4S versions
MA602
: Fits M1S versions
USE ONLY WITH
250V FUSES
DISCONNECT POWER
BEFORE REPLACING FUSES
MA603: Fits M4 versions
MA604: First M1 versions
“X”
A
Section A-A
3
3. Gently lift the entire door UP approximately 1/4" (minimum)
Once lifted, the door will pivot on it’s hinges to expose
the fuse holder
Voltage Selection
1. Open cover, using small blade screwdriver or
Lift Up
similar tool (see illustration on right)
2. Set aside cover/fuse block assembly
3. Pull voltage selector card straight out of housing,
using indicator pin
4. When the fuse holder is installed in the single fuse position,
apply the screwdriver as shown and gently lift up
Use screwdriver as shown, do not use fingers
4. Orient selector card so that desired voltage is
readable at the bottom
NOT here
5. Orient indicator pin to point up when desired
voltage is readable at bottom (note that when indi-
cator pin is fixed, successive voltages are selected by
rotating the card 90° clockwise)
Insert Here
6. Insert voltage selector card into housing, printed
side of card facing forward toward IEC connector
and edge containing the desired voltage first
When the fuse holder is installed in the dual fuse position,
it will normally release as soon as the door is opened
7. Replace cover, and verify that indicator pin shows
the desired voltage
5. Install one (1) AG fuse or two (2) metric fuses (see below)
6. Replace fuse holder into housing
7. Swing and push to snap door back in place
4
2
3
2
Fuse Options
0
0
1
0
1
2
120V
100V
1
0
0
2
North American
single fuse installation
Metric
dual fuse installation
2
3
0
0
4
Install fuses on one side only, do not install
both AG and metric fuses at the same time
230V
240V
185
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options (continued)
M Series
Electrical Schematics
Non-Filtered Models
Filtered Models
FM1 & HM1
VM1
Power On/Off
Power On/Off
Note 2
Note 3
Neutral
H
B
Neutral
K
K
Note 1
Note 2
Note 3
120V
Phase
J
F
L
L
G
Customer
Transformer Primaries
Hot
G
VM2
FM4 & HM4
Power On/Off
240V
A
120V
120V
100V
230V
240V
A
Note 3
120V
20V
B
Power On/Off
Note 2
H
B
A
A
B
K
120V
C
Neutral
Note 2
Note 1
Note 1
100V
H
K
Neutral
C
D
Note 1
Note 4
D
C
D
C
D
120V
Note 3
E
F
G
E
F
120V
Hot
J
F
L
E
F
E
F
Note 4
120V
Customer
J
L
Phase
Transformer Primaries
Note 4
G
Customer
Transformer Primaries
VM4
XM1 & ZM1
120V
100V
230V
240V
20V
Power On/Off
Power On/Off
Note 3
Note 2
A
B
A
H
B
Neutral
Note 1
100V
H
K
Neutral
Note 2
Note 1
Note 1
C
D
C
D
J
F
E
F
G
E
F
120V
Phase
J
L
Hot
G
Customer
Transformer Primaries
XM4 & ZM4
120V
100V
230V
240V






20V
Power On/Off
A
B
A
Note 4

Note 2
100V
H
K
Neutral
Note 1



C
D
C
D
E
F
E
F
120V
Phase
J
L
Note 4
G
Customer
Transformer Primaries






 
 
 
186
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options (continued)
M Series
Case Styles - Non-filtered Models
6VM1
6VM2 & 6VM4
100V
120V
230V
240V
USE ONLY WITH
250V FUSES
USE ONLY WITH
250V FUSES
C
C
DISCONNECT POWER
BEFORE REPLACING FUSES
DISCONNECT POWER
BEFORE REPLACING FUSES
E
D
B
A
E
D
B
A


 
 












6VM1C
6VM4C
100V
USE ONLY WITH
250V FUSES
120V
230V
240V
3
USE ONLY WITH
250V FUSES
C
C
DISCONNECT POWER
DISCONNECT POWER
BEFORE REPLACING FUSES
BEFORE REPLACING FUSES
D
A
D
E
E
A


 
 






6VM1S
6VM2S & 6VM4S
100V
120V
230V
240V
USE ONLY WITH
250V FUSES
USE ONLY WITH
250V FUSES
C
C
DISCONNECT POWER
BEFORE REPLACING FUSES
DISCONNECT POWER
BEFORE REPLACING FUSES
E
D
B
E
D
B
A
A


 
 












6VM1SC
6VM4SC
100V
120V
230V
USE ONLY WITH
250V FUSES
USE ONLY WITH
250V FUSES
C
C
240V
DISCONNECT POWER
BEFORE REPLACING FUSES
DISCONNECT POWER
BEFORE REPLACING FUSES
B
A
E
D
A
E


 
 






187
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options (continued)
M Series
Case Styles - Filtered Models
3EXM1S & 3EZM1S
3EXM4S & 3EZM4S
Threaded
Insert
G
Threaded
Insert
G
1.17*
1.13*
29.7
28.7
*
1.88
47.8
*
1.88
47.8
3.09
78.49
3.09
78.49
Max.
Max.
100V
USE ONLY WITH
250V FUSES
120V
230V
240V
USE ONLY WITH
250V FUSES
C
C
DISCONNECT POWER
BEFORE REPLACING FUSES
DISCONNECT POWER
BEFORE REPLACING FUSES
D
B
A
D
B
A
E
E
*
.0ꢀ0 ꢁ.508]
*
.0ꢀ0 ꢁ.508]


 





 











3EXM4 & 3EZM4
5EHM1 & 5EFM1
Threaded
Insert
G
USE ONLY WITH
250V FUSES
C
DISCONNECT POWER
BEFORE REPLACING FUSES
1.13*
28.7
E
D
*
1.88
47.8
3.09
78.49
B
A
Max.
100V
USE ONLY WITH
250V FUSES
120V
230V
240V
C
DISCONNECT POWER
BEFORE REPLACING FUSES
D
B
A
E
*
.0ꢀ0 ꢁ.508]

 







 








188
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options (continued)
M Series
Case Styles - Filtered Models(continued)
5EFM1C
5EHM4 & 5EFM4
100V
USE ONLY WITH
250V FUSES
USE ONLY WITH
250V FUSES
120V
230V
240V
C
C
DISCONNECT POWER
BEFORE REPLACING FUSES
DISCONNECT POWER
BEFORE REPLACING FUSES
E
D
D
A
E
B
A

 

 









3
5EHM1S & 5EFM1S
5EFM4C
USE ONLY WITH
250V FUSES
100V
120V
230V
240V
USE ONLY WITH
250V FUSES
C
C
DISCONNECT POWER
BEFORE REPLACING FUSES
DISCONNECT POWER
BEFORE REPLACING FUSES
E
D
D
A
E
B
A

 





 





5EFM1SC
5EHM4S & 5EFM4S
100V
USE ONLY WITH
120V
USE ONLY WITH
250V FUSES
C
250V FUSES
230V
C
240V
DISCONNECT POWER
DISCONNECT POWER
BEFORE REPLACING FUSES
BEFORE REPLACING FUSES
E
D
B
D
A
E
A


 

 








189
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options (continued)
M Series
Case Styles - Filtered Models(continued)
5EFM4SC
Case Dimensions
A
B
C
D
E

F

G

Part No.


  
100V
USE ONLY WITH
120V
250V FUSES
230V
     
     
C
240V
DISCONNECT POWER
6VM1
BEFORE REPLACING FUSES
D
A


   
   
E
6VM1C
6VM1S
6VM1SC
     
     


     
     
   
   
6VM2
6VM4



   
   
 



6VM4C
6VM2S
6VM4S
     
     


   
   
6VM4SC
      
      
      
      
      
      
3EXM1S
3EZM1S
3EXM4
3EZM4
Recommended Panel Cutouts
Insert on XM and ZM
.170
Dia.
models only
4.32
3EXM4S
3EZM4S
5EHM1
5EFM1
1.17
29.7
*
*
1.88
47.8
4S Models
     
     
1.13
28.7
*
1S & 4 models
0.13
3.30
R


   
   
.570
14.5
5EFM1C
1.145
29.08
.170
4.32
Dia.
5EHM1S
5EFM1S
     
     


     
     


     
     


.175
4.45
   
   
F
5EFM1SC
.020 [.508]
*
B
5EHM4
5EFM4





   
   
5EFM4C

5EHM4S
5EFM4S
   
   
5EFM4SC
190
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Catalog: 1654001
Issue Date: 06.2011
Corcom Product Guide
Slim Power Entry Module Family with Multiple Options (continued)
M Series
Performance Data
Typical Insertion Loss
Measured in closed 50 Ohm system
5EHM
5EFM
3EXM
3EZM
db
db
db
db
100
100
100
100
90
80
70
60
50
40
30
20
10
90
80
70
60
50
40
30
20
10
90
80
70
60
50
40
30
20
10
90
80
70
60
50
40
30
20
10
0
0
0
0
0.1
1
10
30
0.1
1
10
30
0.1
1
10
30
0.1
1
10
30
.15
.15
Frequency in MHz
Frequency in MHz
Frequency in MHz
Frequency in MHz
3
Common Mode / Asymmetrical (L-G)
Differential Mode / Symmetrical (L-L)
Minimum Insertion Loss
Measured in closed 50 Ohm system
Differential Mode / Symmetrical (Line to Line)
Common Mode / Asymmetrical (Line to Ground)
  
  

   
 
      
 






























     
        

 
191
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
厂商 型号 描述 页数 下载

TE

 		6VM1 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

TE

 		6VM1C 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

TE

 		6VM1S 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

TE

 		6VM1SC 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

TE

 		6VM2 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

TE

 		6VM2S 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

TE

 		6VM4 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

TE

 		6VM4C 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

TE

 		6VM4S 与可选的RFI电源线电源输入模块过滤器一般和医疗应用[ Power Entry Module with Optional RFI Power Line Filters for General and Medical Applications ] 8 页

MACOM

 		6VM4S 修身电源输入模块系列多种选择[ Slim Power Entry Module Family with Multiple Options ] 9 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.181328s
