CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS
SERIES
SW
SWZ
SERIES
UPGRADE
◆FEATURES
ꢀSW：High Capacitance,Low ESR
ꢀSWZ：High Capacitance,Ultra Low ESR
・RoHS Compliance
・Lead free reflow soldering is available
ꢀ(260℃,10sec):(Available for MSL3)
◆SPECIFICATIONS
SW
SWZ
Series
2.7mm
2.9mm
－55～＋105℃
1.9mm
Temperature Range(℃)
Rated Voltage Range(V.DC)
Rated Cap Range(μF)
2～8
2～6.3
2～10
68～220
120～470
47～330
Capacitance Tolerance(20℃/120Hz)
Leakage Current(after 5 minutes)(μA)
±20％
≦0.04CV
（Tanδ）
≦0.1
≦0.1
Dissipation Factor(20℃/120Hz)
Equivalent Series Resistance(ESR)
(mΩ)(20℃/100kHz)
9～18
9
4.5～25
3,500
Maximum Allowable Ripple Current(mA r.m.s)(100kHz)
Surge Voltage
1,800～3,500
2,500(8V)
Rated voltage ×1.25
Within ±20% of the initial value
≦200% of initial specified value
≦initial specified value
ΔC
Endurance
(105℃, 2000hrs, Rated Voltage applied)
Tanδ
LC
Within －20%～+40% of the initial value
Within －20%～+60% of the initial value
ΔC
Damp heat(Steady state)
(60℃, 90%RH, 500hrs, No-applied voltage)
≦200% of initial specified value
≦300% of initial specified value
Tanδ
LC
