2W005G THRU 2W10G
VOLTAGE 50V ~ 1000V
Elektronische Bauelemente
2.0 AMP Glass Passivated Bridge Rectifiers
RoHS Compliant Product
A suffix of "-C" specifies halogen-free.
WOL
.358
(9.1)
MAX.
.290(7.4)
.270(6.9)
1.2
(30.5)
MIN.
1.0
(25.4)
MIN.
ƔFEATURES
.
.
.
Surge overload rating – 60 amperes peak
Ideal for printed circuit board
.032(0.8)
.030(0.7)
POS.
LEAD
Reliable low cost construction utilizing
Molded plastic technique results in expensive product
.
.
Mounting position: Any
.220(5.6)
.180(4.6)
.220(5.6)
.180(4.6)
Weight: 1.6 grams
Dimensions in inches and (millimeters)
ƔMAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25 к ambient temperature unless otherwise specified.
Resistive or inductive load, 60Hz,
For capacitive load, derate current by 20%.
2W005G
50
35
TYPE NUMBER
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
2W01G 2W02G 2W04G 2W06G 2W08G 2W10G UNITS
100
70
200
140
200
400
280
400
600
420
600
800
560
800
1000
700
V
V
V
Maximum DC Blocking Voltage
50
100
1000
Maximum Average Forward Rectified Current
0.375” (9.5mm) Lead Lengths at Ta=25к
Peak Forward Surge Current, 8.3 ms Single
Half Sine-Wave Superimposed
2.0
A
60
A
on Rated Load (JEDEC method)
I2t Rating for Fusing (t<8.3ms)
15.0
1.1
A2S
V
Maximum Forward Voltage Drop
Per Element at 2.0 A Peak
Maximum DC Reverse Current at Ta=25 к
at Rated DC Blocking Voltage at Ta=100 к
Typical Junction Capacitance per Element (Note 1)
Operating Temperature Range TJ
Storage Temperature Range TSTG
NOTES:
10.0
1.0
30
µA
mA
pF
к
-55 ~ +150
-55 ~ +150
к
1. Measured at 1MHz and applied reverse voltage of 4.0V D.C.
