1ST112WS
SILICON EPITAXIAL PLANAR SWITCHING DIODES
PINNING
DESCRIPTION
Cathode
PIN
1
Anode
2
2
1
W2
Top View
Marking Code: "W2"
Simplified outline SOD-323 and symbol
O
Absolute Maximum Ratings (Ta = 25 C)
Parameter
Symbol
Value
Unit
Peak Reverse Voltage
VRM
VR
40
V
V
Reverse Voltage
40
Average Forward Current
Peak Forward Current
IF(AV)
IFM
200
mA
mA
A
600
Non-Repetitive Peak Forward Surge Current (t = 1 s)
Junction Temperature
IFSM
Tj
1
O
C
150
O
C
Storage Temperature Range
Tstg
- 55 to + 150
O
Characteristics at Ta = 25 C
Parameter
Symbol
VF
Max.
1.1
Unit
V
Forward Voltage
at IF = 200 mA
Reverse Current
at VR = 15 V
at VR = 35 V
50
500
IR
nA
Total Capacitance
at VR = 0 V, f = 1 MHz
CT
trr
4
pF
ns
Reverse Recovery Time
at VR = 6 V, IF = 10 mA, Irr = 0.1·IR, RL = 100 Ω
10
SEMTECH ELECTRONICS LTD.
(Subsidiary of Sino-Tech International Holdings Limited, a company
listed on the Hong Kong Stock Exchange, Stock Code: 724)
®
Dated : 07/04/2009
