■ Actuators
Note: 1. Unless otherwise specified, all units are in millimeters and a tolerance of ± 0.4 mm applies to all dimensions.
2. These Actuators are not provided with Switches.
Hinge Lever
Two, M4 30
Two, M4
ZAA-1
Model
OF max.
RF min.
PT max.
OT min.
MD max. 2.2 mm
FP max. 32.9±1.6 mm
Z-15G-B
500 gf
170 gf
6 mm
X-10G-B
500 gf
170 gf
6 mm
12.7 mm
3.3 mm
12.7 mm
Stainless steel
60R
Note: This Actuator can be used with the Z-15G(-B)
and X-10G(-B). When mounting the Switch, set
the overtravel to between 32% and 100%, taking
into consideration the operating body and the dis-
tance between the Actuator and the dog.
Two, M4 30
Two, M4
Hinge Roller Lever
ZAA-2
Model
OF max.
RF min.
PT max.
Z-15G-B
500 gf
170 gf
6 mm
X-10G-B
500 gf
170 gf
6 mm
9.5 dia. 4.8
(stainless-steel roller) OT min.
12.7 mm
12.7 mm
3.3 mm
MD max. 2.2 mm
FP max. 44.5±1.6 mm
Stainless steel
58.5R
Note: This Actuator can be used with the Z-15G(-B)
and X-10G(-B). When mounting the Switch, set
the overtravel to between 32% and 100%, taking
into consideration the operating body and the
distance between the Actuator and the dog.
Panel Mount Roller Lever
48
12.7 dia. (Note 1)
ZAQ-22
PT
0.25
23.3
4.8
Two hex nuts
Model
ZAQ-22
Z-15E-B DZ-10G-B
5-mm thickness, 19 mm
between opposing edges
With groove for roller
penetration
OF max. 850 gf
RF min. 114 gf
PT max. 2 mm
1,131 gf
114 gf
2 mm
OP
M12 1 mounting
screw
(Note 3)
18.9
1.6
14.5
dia.
OT min. 3.58 mm 1 mm
20.7
MD max. 0.15 mm 0.46 mm
23.9
OP
37±0.8 mm 35.4±1.2 mm
Note: This Actuator (panel mount roller
plunger) can be used with
Spring washer
(Note 2)
Two, M4 25
screws
0.2
25.4
20.7
standard pin plungers (Z-15G(-B),
Z-15E(-B), and DZ-10G-1A(-1B)).
11.9
49.2
The ZAQ-22 is constructed of
ferrous material. Therefore, It
cannot be used with X switches
due to the permanent magnet used
within those models.
Note: 1. Stainless-steel pin plunger
2. Bronze frame
3. Incomplete screw section part
with a maximum of 1.5 mm.
Z/A/X/DZ Common Accessories
