PZTA14
NPN SILICON TRANSISTOR
ABSOLUTE MAXIMUM RATING (TA=25°C)
PARAMETER
SYMBOL
VCBO
VCES
VEBO
PC
RATINGS
UNIT
V
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Power Dissipation
Collector Current
30
30
V
10
1
V
W
IC
500
mA
°C
°C
Junction Temperature
Storage Temperature
TJ
150
TSTG
-55 ~ +150
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS (TA =25°C, unless otherwise specified)
PARAMETER
SYMBOL
BVCES
ICBO
TEST CONDITIONS
IC=100μA, IB=0
MIN TYP MAX UNIT
Collector-Emitter Breakdown Voltage
Collector Cut-Off Current
30
20000
125
V
VCB=30V, IE=0
100
100
nA
nA
Emitter Cut-Off Current
IEBO
VEB=10V, IC=0
DC Current Gain
hFE
VCE=5V, IC=100mA
Collector-Emitter Saturation Voltage
Base-Emitter on Voltage
VCE(SAT) IC=100mA, IB=0.1mA
1.5
2.0
V
V
VBE(ON)
fT
VCE=5V, IC=100mA
Current Gain Bandwidth Product
VCE=5V, IC=10mA, f=100MHz
MHz
Pulse test: Pulse Width<300μs, Duty Cycle=2%
