5.0 AMP REMOTE SENSE
VOLTAGE REGULATOR
EZ1087
TEL:805-498-2111 FAX:805-498-3804 WEB:http://www.semtech.com
April 7, 1998
DESCRIPTION
FEATURES
The EZ1087 5.0A voltage regulator is a monolithic
integrated circuit designed for use in applications
requiring a well regulated positive output voltage with
low input-output differential voltage requirements and
where remote sensing of the output voltage is desired
to compensate for connector, wiring and pc board
trace resistances or other voltage losses. Other
outstanding features include full power usage up to
5.0A of load current, internal current limiting, and
thermal shutdown. Specifications guarantee 3.30 VDC
output from a 4.75 VDC input.
•= Low dropout performance, 1.3V max.
•= Kelvin remote sense inputs
•= Line regulation typically 0.015%
•= Load regulation typically 0.1%
•= 5-pin TO-220 package
ORDERING INFORMATION
DEVICE
PACKAGE
VOUT VOLTS
APPLICATIONS
EZ1087CT
TO-220
1.30 to 5.7
•= GTL+ bus supplies
ABSOLUTE MAXIMUM RATINGS
BLOCK DIAGRAM
Parameter
Symbol Maximum Units
Input Voltage
VIN
7
V
Sense Pins
Differential Voltage
V+S - V-S
4
V
Sense Pin Voltage
Range
VSP
PD
Note 1
V
W
Power Dissipation
Internally
Limited
Thermal Resistance
Junction to Case
2.5
50
°C/W
°C/W
°C
θJC
θJA
Thermal Resistance
Junction to Ambient
Operating Junction
Temperature Range
TJ
0 to 125
-65 to 150
260
PIN CONFIGURATION
Storage Temperature
Range
TSTG
TLEAD
°C
EZ1087
Lead Temperature
(Soldering) 10 Sec
PIN FUNCTION
°C
1
2
3
4
5
- SENSE
ADJ
Note:
(1) (VOUT - 1V) ≤ V±SENSE ≤ (VOUT + 0.4V)
OUTPUT
INPUT
+ SENSE
TAB IS OUTPUT
1
