NPN Low Saturation Transistor
(continued)
Electrical Characteristics
TA = 25°C unless otherwise noted
Symbol
Parameter
Test Conditions
Min
Max
Units
OFF CHARACTERISTICS
Collector-Emitter Breakdown Voltage
Collector-Base Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cutoff Current
25
35
5
V
V
V
BVCEO
BVCBO
BVEBO
ICBO
IC = 10 mA
IC = 100 mA
IE = 100 mA
100
10
nA
uA
VCB = 30 V
VCB = 30 V, TA=100°C
Emitter Cutoff Current
100
nA
IEBO
VEB = 4V
ON CHARACTERISTICS*
DC Current Gain
hFE
70
100
75
-
IC = 50 mA, VCE = 2 V
IC = 1 A, VCE = 2 V
IC = 2 A, VCE = 2 V
IC = 6 A, VCE = 2 V
300
15
Collector-Emitter Saturation Voltage
300
600
mV
VCE(sat)
IC = 1 A, IB = 100 mA
IC = 3 A, IB = 300 mA
Base-Emitter Saturation Voltage
Base-Emitter On Voltage
1.25
1
V
V
VBE(sat)
VBE(on)
IC = 1 A, IB = 100 mA
IC = 1 A, VCE = 2 V
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
Cobo
50
pF
-
VCB = 10 V, IE = 0, f = 1MHz
Transition Frequency
fT
150
IC = 100 mA,VCE = 5 V, f=100MHz
*Pulse Test: Pulse Width £ 300 ms, Duty Cycle £ 2.0%
Page 2 of 2
ã
1998 Fairchild Semiconductor Corporation
fzt649.lwpPrNC 7/10/98 revB
