TM
8kV 500mA 40nS
HVCA
UX-FOB
High Voltage Power Diodes provide fast recovery times
Outline Drawings : mm
UX-FOB
is high reliability resin molded type high voltage
diode in small size package which is sealed a multilayed
mesa type silicon chip by epoxy resin.
Features
High speed switching of 40 nsec
8,000 V peak reverse voltage
High surge resisitivity for CRT discharge
High reliability design
Suited for high freuqency applications
Cathode Mark
Applications
X light Power supply
Mark
Type
Laser
Voltage doubler circuit
Microwave emission power
UX-FOB
Maximum Ratings and Characteristics
Absolute Maximum Ratings
Symbols
VRRM
IO
Items
Condition
UX-FOB
8
Units
kV
Repetitive Peak Renerse Voltage
Average Output Current
Suege Current
500
Ta=25°C,Resistive Load
mA
Apeak
°C
IFSM
20
155
j
T
Junction Temperature
125
Allowable Operation Case Temperature
Storage Temperature
Tc
°C
Tstg
-40 to +155
°C
Electrical Characteristics (Ta=25°C Unless otherwise specified )
Items
Symbols
VF
UX-FOB
12
Conditions
at 25°C,IF=IF(AV)
at 25°C,VR=VRRM
Units
V
Maximum Forward Voltage Drop
Maximum Reverse Current
IR1
0.5
5.0
µA
IR2
RRM
at 100°C,VR=V
µA
nS
Maximum Reverse Recovery Time
Junction Capacitance
Trr
at 25°C
40
-
Cj
at 25°C,VR=0V,f=1MHz
pF
GETE ELECTRONICS CO.,LTD
Http://www.getedz.com E-mail:sales@getedz.com
2012
