IXGH 24N60A
Symbol
gfs
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
min. typ. max.
TO-247 AD Outline
IC = IC90; VCE = 10 V,
9
13
S
Pulse test, t ≤ 300 µs, duty cycle ≤ 2 %
Cies
Coes
Cres
1500
135
40
pF
pF
pF
VCE = 25 V, VGE = 0 V, f = 1 MHz
Qg
90
11
30
120 nC
15 nC
40 nC
Qge
Qgc
IC = IC90, VGE = 15 V, VCE = 0.5 VCES
td(on)
tri
25
15
ns
ns
1 = Gate
Inductive load, TJ = 25°C
2 = Collector
3 = Emitter
Tab = Collector
IC = IC90, VGE = 15 V, L = 100 µH,
VCE = 0.8 VCES, RG = Roff = 10 Ω
Eon
td(off)
tfi
0.6
150
110
1.5
mJ
200 ns
270 ns
mJ
Remarks: Switching times may increase
for VCE (Clamp) > 0.8 • VCES, higher TJ or
increased RG
Eoff
td(on)
tri
25
15
ns
ns
Inductive load, TJ = 125°C
IC = IC90, VGE = 15 V, L = 100 µH
VCE = 0.8 VCES, RG = Roff = 10 Ω
Eon
td(off)
tfi
0.8
250
400
2.3
mJ
ns
Remarks: Switching times may increase
for VCE (Clamp) > 0.8 • VCES, higher TJ or
increased RG
ns
Eoff
mJ
RthJC
RthCK
0.83 K/W
K/W
0.25
IXGH 24N60A characteristic curves are located on the
IXGH 24N60AU1 data sheet.
