DXTN07100BP5-13

型号:

DXTN07100BP5-13

描述:

100V NPN型中功率低饱和晶体管PowerDI®5[ 100V NPN MEDIUM POWER LOW SATURATION TRANSISTOR PowerDI®5 ]

品牌:

DIODES[ DIODES INCORPORATED ]

页数:

7 页

PDF大小:

178 K

A Product Line of
Diodes Incorporated
DXTN07100BP5
100V NPN MEDIUM POWER LOW SATURATION TRANSISTOR
PowerDI®5
Features
Mechanical Data
43% smaller than SOT223; 60% smaller than TO252
Maximum height just 1.1mm
Rated up to 3.2W
Case: PowerDI®5
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
VCEO = 100V
IC = 2A; ICM = 6A
Low Saturation, high gain transistor,
Lead, Halogen and Antimony Free, RoHS Compliant (Note 1)
“Green” Device (Note 2)
Weight: 0.093 grams (approximate)
Features
Regular circuits
C
C
B
E
B
E
Top View
Bottom View
Device Schematic
Pin-out diagram
Ordering Information (Note 3)
Part Number
DXTN07100BP5-13
Case
PowerDI®5
Packaging
5000/Tape & Reel
Notes:
1. No purposefully added lead. Halogen and Antimony Free.
2. Diodes Inc’s “Green” Policy can be found on our website at http://www.diodes.com
3. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
DTN7100B = Product Type Marking Code
= Manufacturers’ Code Marking
K = Factory Designator
YYWW = Date Code Marking
YY = Last Two Digits of Year (ex: 09 for 2009)
WW = Week code (01 to 53)
DTN7100B
YYWWK
PowerDI is a registered trademark of Diodes Incorporated.
1 of 7
www.diodes.com
March 2010
© Diodes Incorporated
DXTN07100BP5
Document number: DS32023 Rev. 2 - 2
A Product Line of
Diodes Incorporated
DXTN07100BP5
Maximum Ratings @TA = 25°C unless otherwise specified
Characteristic
Collector-Base Voltage
Symbol
VCBO
VCEO
VEBO
IC
Value
120
100
5
Unit
V
Collector-Emitter Voltage
Emitter-Base Voltage
V
V
Continuous Collector Current
Peak Pulse Current
2
A
6
A
ICM
Thermal Characteristics
Characteristic
Power Dissipation @ TA = 25°C (Note 4)
Symbol
PD
Value
3.2
Unit
W
39
°C/W
W
Thermal Resistance, Junction to Ambient Air (Note 4) @TA = 25°C
Power Dissipation @ TA = 25°C (Note 5)
Rθ
JA
1.7
PD
75
°C/W
W
Thermal Resistance, Junction to Ambient Air (Note 5) @TA = 25°C
Power Dissipation @ TA = 25°C (Note 6)
Rθ
JA
0.74
169
PD
°C/W
Thermal Resistance, Junction to Ambient Air (Note 6) @TA = 25°C
Thermal Resistance, Junction to Collector Terminal
Operating and Storage Temperature Range
Rθ
Rθ
JA
8.9
°C/W
°C
JT
-55 to +150
TJ, TSTG
Notes:
4. Device mounted on FR-4 PCB, single sided 2 oz. copper, collector pad dimensions 50mm x 50mm.
5. Device mounted on FR-4 PCB, single sided 1 oz. copper, collector pad dimensions 50mm x 50mm.
6. Device mounted on FR-4 PCB, single sided 1 oz. copper, minimum recommended pad layout.
PowerDI is a registered trademark of Diodes Incorporated.
2 of 7
www.diodes.com
March 2010
© Diodes Incorporated
DXTN07100BP5
Document number: DS32023 Rev. 2 - 2
A Product Line of
Diodes Incorporated
DXTN07100BP5
10
1
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
VCE(sat)
Limited
See note 3
See note 4
See note 5
DC
1s
100ms
100m
10ms
1ms
100µs
Single Pulse. Tamb=25°C
See note 3
10m
100m
1
10
100
0
25
50
75
100 125 150 175
VCE Collector-Emitter Voltage (V)
Temperature (°C)
Safe Operating Area
Derating Curve
Single Pulse. Tamb=25°C
See note 3
40
30
20
10
0
See note 3
D=0.5
100
10
1
D=0.2
Single Pulse
D=0.05
D=0.1
100µ 1m 10m 100m
1
10
100
1k
100µ 1m 10m 100m
1
10
100
1k
Pulse Width (s)
Pulse Width (s)
Transient Thermal Impedance
Pulse Power Dissipation
4
3
2
1
0
180
T(amb)=25°C
T(amb)=25°C
160
140
120
100
80
1 oz. weight Copper
2 oz. weight Copper
60
1 oz. weight Copper
2 oz. weight Copper
100
40
20
10
1000
10000
10
100
1000
10000
Copper Area (sq mm)
Copper Area (sq mm)
Power Rating vs. Cu Area
Thermal Resistance vs. Cu Area
PowerDI is a registered trademark of Diodes Incorporated.
3 of 7
www.diodes.com
March 2010
© Diodes Incorporated
DXTN07100BP5
Document number: DS32023 Rev. 2 - 2
A Product Line of
Diodes Incorporated
DXTN07100BP5
Electrical Characteristics @TA = 25°C unless otherwise specified
Characteristic
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage (Note 7)
Emitter-Base Breakdown Voltage
Symbol
V(BR)CBO
V(BR)CEO
V(BR)EBO
Min
120
100
5
Typ
Max
Unit
V
Test Condition
C = 100μA
C = 10mA
I
I
I
V
V
E = 100μA
VCB = 100V
VCB = 100V, Tamb = 100 °C
VEB = 4V
0.1
10
Collector Cutoff Current
ICBO
IEBO
0.13
0.23
μA
μA
V
Emitter Cutoff Current
0.1
IC = 1A, IB = 100mA
0.3
0.5
Collector-Emitter Saturation Voltage (Note 7)
VCE(sat)
I
C = 2A, IB = 200mA
Base-Emitter Saturation Voltage (Note 7)
Base-Emitter Turn-On Voltage (Note 7)
0.9
0.8
1.25
1.00
V
V
VBE(sat)
VBE(on)
IC = 1A, IB = 100mA
IC = 1A, VCE = 2V
IC = 50mA, VCE = 2V
IC = 500mA, VCE = 2V
IC = 1A, VCE = 2V
IC = 2A, VCE = 2V
300
70
100
55
200
200
110
55
DC Current Gain (Note 7)
hFE
25
IC = 100mA, VCE = 5V
f = 100MHz
Transition Frequency
Output Capacitance
Switching Times
140
175
MHz
pF
fT
30
Cobo
ton
toff
80
1200
VCB = 10A, f = 1MHz
IC = 500mA, VCC = 10V,
IB1 = IB2 = 50mA
ns
ns
Notes:
7. Pulse Test: Pulse width 300μs. Duty cycle 2.0%.
PowerDI is a registered trademark of Diodes Incorporated.
4 of 7
www.diodes.com
March 2010
© Diodes Incorporated
DXTN07100BP5
Document number: DS32023 Rev. 2 - 2
A Product Line of
Diodes Incorporated
DXTN07100BP5
Typical Characteristic
1
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
Tamb=25°C
IC/IB=10
IC/IB=100
IC/IB=50
150°C
100°C
100m
10m
IC/IB=20
IC/IB=10
25°C
-55°C
1m
10m
100m
1
10m
100m
1
IC Collector Current (A)
IC Collector Current (A)
VCE(sat) v IC
VCE(sat) v IC
150°C
1.2
1.0
0.8
0.6
0.4
0.2
IC/IB=10
VCE=2V
-55°C
25°C
200
100
150°C
-55°C
100°C
0
1m
10m
100m
1
10
1m
10m
100m
1
IC Collector Current (A)
IC Collector Current (A)
hFE v IC
VBE(sat) v IC
50
45
40
35
30
25
20
15
10
5
1.2
1.0
0.8
0.6
0.4
0.2
VCE=2V
f = 1MHz
-55°C
25°C
Cobo
150°C
100°C
1
0
10m
100m
1
10
100
1m
10m
100m
Voltage(V)
IC Collector Current (A)
Capacitance v Voltage
VBE(on) v IC
PowerDI is a registered trademark of Diodes Incorporated.
5 of 7
www.diodes.com
March 2010
© Diodes Incorporated
DXTN07100BP5
Document number: DS32023 Rev. 2 - 2
A Product Line of
Diodes Incorporated
DXTN07100BP5
Package Outline Dimensions
A
PowerDI®5
Min
D
b2
D2
Dim
A
Max
1.15
0.43
0.99
1.88
4.05
A2
1.05
A2
b1
b2
D
D2
E
0.33
0.80
1.70
3.90
L
E2
E
3.054 Typ
6.60
1.84 Typ
5.45
3.549 Typ
E1
6.40
5.30
e
W
E1
E2
L
L1
W
L1
0.75
0.50
1.10
0.95
0.65
1.41
e
b1
b1
A2
All Dimensions in mm
Suggested Pad Layout
Z
Dimensions Value (in mm)
C
Z
6.6
1.4
3.6
0.8
4.7
3.87
0.9
X1
X2
Y1
Y2
C
E1
X1
X2
E1
Y1
Y2
PowerDI is a registered trademark of Diodes Incorporated.
6 of 7
www.diodes.com
March 2010
© Diodes Incorporated
DXTN07100BP5
Document number: DS32023 Rev. 2 - 2
A Product Line of
Diodes Incorporated
DXTN07100BP5
IMPORTANT NOTICE
DIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
(AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).
Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes
without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the
application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or
trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume
all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated
website, harmless against all damages.
Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel.
Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and
hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or
indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.
Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings
noted herein may also be covered by one or more United States, international or foreign trademarks.
LIFE SUPPORT
Diodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express
written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:
A. Life support devices or systems are devices or systems which:
1. are intended to implant into the body, or
2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in the
labeling can be reasonably expected to result in significant injury to the user.
B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause
the
failure of the life support device or to affect its safety or effectiveness.
Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any
use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related
information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its
representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.
Copyright © 2009, Diodes Incorporated
www.diodes.com
PowerDI is a registered trademark of Diodes Incorporated.
7 of 7
www.diodes.com
March 2010
© Diodes Incorporated
DXTN07100BP5
Document number: DS32023 Rev. 2 - 2
厂商 型号 描述 页数 下载

RADIOMETRIX

DXT-433-TX2A [ DX series remote control boards ] 7 页

RADIOMETRIX

DXT-434.650-NTX2B [ DX series remote control boards ] 7 页

DIODES

DXT2010P5 60V NPN中功率晶体管PowerDI®5[ 60V NPN MEDIUM POWER TRANSISTOR PowerDI®5 ] 7 页

DIODES

DXT2010P5-13 60V NPN中功率晶体管PowerDI®5[ 60V NPN MEDIUM POWER TRANSISTOR PowerDI®5 ] 7 页

DIODES

DXT2011P5 100V NPN低SAT中功率晶体管PowerDI®5[ 100V NPN LOW SAT MEDIUM POWER TRANSISTOR PowerDI®5 ] 7 页

DIODES

DXT2011P5-13 100V NPN低SAT中功率晶体管PowerDI®5[ 100V NPN LOW SAT MEDIUM POWER TRANSISTOR PowerDI®5 ] 7 页

DIODES

DXT2012P5 60V PNP中功率晶体管PowerDI®5[ 60V PNP MEDIUM POWER TRANSISTOR PowerDI®5 ] 7 页

DIODES

DXT2012P5-13 60V PNP中功率晶体管PowerDI®5[ 60V PNP MEDIUM POWER TRANSISTOR PowerDI®5 ] 7 页

DIODES

DXT2013P5 100V PNP中功率晶体管PowerDI®5[ 100V PNP MEDIUM POWER TRANSISTOR PowerDI®5 ] 7 页

DIODES

DXT2013P5-13 100V PNP中功率晶体管PowerDI®5[ 100V PNP MEDIUM POWER TRANSISTOR PowerDI®5 ] 7 页

PDF索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引:

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

0.239984s
