BZX84C2V4
DC COMPONENTS CO., LTD.
THRU
RECTIFIER SPECIALISTS
R
BZX84C39
TECHNICAL SPECIFICATIONS OF SURFACE MOUNT ZENER DIODES
FEATURES
* Voltage Range:2.4V to 39V
* Ideally Suited for Automated Assembly Process
* 410mW Power Dissipation
SOT-23
.020(0.50)
.012(0.30)
MECHANICAL DATA
* Case: Molded plastic
.108(0.65)
.089(0.25)
.063(1.60)
.055(1.40)
* Terminals:Solder plated, solderable per
MIL-STD-202E, Method 208 guaranteed
* Polarity: See Diagram
.045(1.15)
.034(0.85)
.091(2.30)
.067(1.70)
* Mounting position: Any
* Weight: 0.008 grams
.118(3.00)
.110(2.80)
.0043(0.11)
.0035(0.09)
.051(1.30)
.035(0.90)
.026(0.65)
.010(0.25)
.004
(0.10)
.027(0.67)
.013(0.32)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25oC ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Max
Dimensions in inches and (millimeters)
SYMBOL
VALUE
410
UNITS
mW
Zener Current see Table "Characteristics"
Power Dissipation (Notes 1) at Tamb=25oC
Ptot
IFSM
Peak Forward Surge Current, 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method) (Notes 2)
Maximum Forward Voltage at IF=100mA
2.0
1.2
Amps
Volts
oC
VF
Operating and Storage Temperature
TJ,Tstg
-55 to + 150
Notes: 1. Mounted on 5.0mm2 (.013mm thick) land areas.
2. Measured on 8.3ms, single half sine-wave or equivalent square wave, duty cycle = 4 pulses per minute maximum.
