CHENMKO ENTERPRISE CO.,LTD
1SS388PT
SURFACE MOUNT
SCHOTTKY BARRIER DIODE
VOLTAGE 40 Volts CURRENT 0.1 Ampere
APPLICATION
* Low current rectification and high speed switching
SC-79/SOD-523
FEATURE
* Extremely small surface mounting type. (SC-79/SOD-523)
* Io=200mA guaranteed despite size
Cathode
* Low VF. (VF=0.40V Typ. at 200mA)
(1)
(2)
0.75~0.85
0.25~0.35
CONSTRUCTION
1.1~1.3
* Silicon epitaxial planar
0.5~0.77
0.07~0.17
1.5~1.7
CIRCUIT
(2)
(1)
SC-79/SOD-523
Dimensions in millimeters
MAXIMUM RATINGES ( At TA = 25oC unless otherwise noted )
RATINGS
SYMBOL
VRRM
VRMS
VDC
1SS388PT
UNITS
Volts
Volts
Volts
Amps
Amps
pF
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
40
28
Maximum DC Blocking Voltage
40
Maximum Average Forward Rectified Current
Peak Forward Surge Current at 8.3 mSec single half sine-wave
Typical Junction Capacitance between Terminal (Note 1)
Maximum Operating Temperature Range
IO
0.1
1.0
2.0
+125
IFSM
CJ
oC
TJ
oC
Storage Temperature Range
TSTG
-40 to +125
ELECTRICAL CHARACTERISTICS ( At TA = 25oC unless otherwise noted )
1SS388PT
0.36 at IF= 10mA
5.0
CHARACTERISTICS
Maximum Instantaneous Forward Voltage
Maximum Average Reverse Current at VR= 10V
SYMBOL
UNITS
Volts
VF
IR
0.28 at IF= 1mA
0.60 at IF= 50mA
uAmps
2001-6
NOTES : 1. Measured at 1.0 MHZ and applied reverse voltage of 1.0 volts.
2. ESD sensitive product handling required.
