Zowie Technology Corporation
Switching Diode
Lead free product
Halogen-free type
CATHODE
1
ANODE
2
1SS355GH
1
2
SOD-323
MAXIMUM RATINGES ( At TA = 25oC unless otherwise noted )
RATINGS
Symbol
UNITS
Volts
1SS355GH
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
V
RRM
RMS
90
V
63
80
Volts
Maximum DC Blocking Voltage
V
DC
Volts
Maximum Average Forward Rectified Current
Peak Forward Surge Current at 1Sec.
I
O
0.1
0.5
Amps
Amps
I
FSM
Typical Junction Capacitance between Terminal
(Note 1)
3.0
pF
C
J
Maximum Reverse Recovery Time (Note 2)
Maximum Operating Temperature Range
T
RR
4.0
nSec
oC
T
J
+125
oC
Storage Temperature Range
T
STG
-55 to +125
ELECTRICAL CHARACTERISTICS ( At TA = 25oC unless otherwise noted )
CHARACTERISTICS
Symbol
1SS355GH
UNITS
Volts
Maximum Instantaneous Forward Voltage at
IF= 100mA
1.20
V
F
uAmps
I
R
Maximum Average Reverse Current at VR= 80V
0.1
NOTES :1. Measured at 1.0 MHZ and applied reverse voltage of 6.0 volts.
2. Measured at applied froward current of 10mA and reverse voltage of 6.0 volts.
3. ESD sensitive product handling required.
REV. 0
Zowie Technology Corporation
