HIGH SPEED SWITCHING DIODE
1SS133
DO - 34 Glass
FEATURES :
• High switching speed: max. 4 ns
• Continuous reverse voltage:max. 80 V
• Repetitive peak reverse voltage:max. 90 V
• Pb / RoHS Free
1.00 (25.4)
0.078 (2.0 )max.
min.
0.118 (3.0)
Cathode
max.
Mark
1.00 (25.4)
min.
0.019 (0.50)max.
MECHANICAL DATA :
Case: DO-34 Glass Case
Weight: approx. 0.093g
Dimensions in inches and ( millimeters )
Maximum Ratings and Thermal Characteristics (Rating at 25 °C ambient temperature unless otherwise specified.)
Parameter
Symbol
Value
90
Unit
V
Maximum Repetitive Peak Reverse Voltage
Maximum Continuous Reverse Voltage
Maximum Average Forward Current
Maximum Peak Forward Current
Maximum Power Dissipation
VRM
VR
IF
80
V
130
mA
mA
mW
mA
°C
IFM
PD
IFSM
TJ
400
300
Maximum Non-repetitive Peak Forward Current
Maximum Junction Temperature
Storage Temperature Range
600
175
TS
-65 to + 175
°C
Electrical Characteristics (Ta = 25°C unless otherwise noted)
Test Condition
VR = 80 V
IF = 100 mA
Min.
Typ.
Max.
Unit
Parameter
Symbol
IR
VF
CT
Reverse Current
-
-
-
-
-
-
0.5
1.2
2.0
mA
V
Forward Voltage
f = 1MHz ; VR = 0.5
Capacitance between terminals
pF
IF = 10 mA , VR = 6 V
Reverse Recovery Time
Trr
-
-
4.0
ns
RL = 50 W , Irr = 1/10 IR
