Part Number:
Status:
0190430010
Active
Description:
Three Way Connector, Dual Male, Single Female Quick Disconnect Adapter, .250
x .032 Tab Size, Non-Plated
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Crimp Quality Equipment
MolexKits
Series
Quick Disconnects
19043
Yes
Yes
image - Reference only
China RoHS
EU RoHS
ELV and RoHS
Compliant
Product Name
Type
Adapter
Quick Disconnect
REACH SVHC
Contains SVHC: No
Halogen-Free
Status
Physical
Barrel Type
N/A
Dual
Gender
Not Reviewed
Need more information on product
environmental compliance?
Glow-Wire Compliant
Insulation
Lock to Mating Part
Orientation
Packaging Type
Tab Thickness
Tab Width
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
No
None
None
Straight
Bag
0.81mm (.032")
6.35mm (.250")
N/A
N/A
N/A
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Electrical
Voltage - Maximum
N/A
Search Parts in this Series
19043Series
Material Info
Old Part Number
VWA-0
Reference - Drawing Numbers
Sales Drawing
SD-19043-003
