COMMUNICATIONS TEST & MEASUREMENT SOLUTIONS
OVF-1
“Pen-size”Visual Fault Locator
Key Features
•Rugged metal housing, pen-size format
•Lightweight
•Universal push-pull interfaces (UPP) for
2.5 mm and 1.25 mm
•Visible laser light at 635 nm
•Usable with single-mode and multimode fibers
•Range >5 km
•CW and blink modes
•Long battery life (>40 hours)
Faultlocationinfiberopticsnetworks
The OVF-1 is specially designed for field personnel who need an efficient and economi-
cal tool for fiber tracing, fiber routing and continuity checking in an optical network
duringandafterinstallation.
Fiber breaks, microbends, and poor optical splices are clearly visible as light glows
throughthefiberbufferorouterjacket.
FaultlocationbehindopticalconnectorswheretheuseofOTDRsislimitedduetodead
zonesisnowpossiblewiththeOVF-1.
The blink mode improves visibility for use in bright ambient light. The highly efficient
laser diode operates at short wavelengths of 635 nm to ensure that the emitted light is
clearly visible to the human eye. Fibre tracing is possible over more than 5 km for single-
mode fibers.
Withthenewuniversalpush-pull(UPP)adapter,matchingofallstandard2.5mmoptical
connectortypesispossible. Theconnectorisheldwithoutadditionalmechanicalfixing.
Anadditionalexternaladapterconvertsfrom2.5mmUPPto.125mmUPP.Thisadapter
allowstoconnecttheOVF-1toopticalconnectorswith1.25mmferrulee.g. LC, MUor
F3000.
TheOVF-1comesinaruggedmetalhousing.Withitscompact,lightweightdesign,itfits
easilyinavestpocket.
