CRYSTAL CONTROLLED OSCILLATORS
PACKAGE CHARACTERISTICS
TABLE 6.0
Metal package: solder sealed, grounded case, solder tinned pins.
RoHS 5/6 compliant, see solder profile below.
Pin Connections
Package
Solder Process
ENVIRONMNETAL CHARACTERISTICS
TABLE 7.0
CONTROL VOLTAGE
Shock
Vibration
100G’s, 6mS, halfsine per MIL-STD-202F, Method 213B, Test Condition C
0.06” D.A. or 10G peak 10 to 500 Hz, per MIL-STD-202F, Method 204D, Test
condition A
Notes:
1) Labels will include the calibration frequency at the time of ship.
2) Initial calibration @ 25 C, Vc=1.65Vdc, at time of shipment.
3) Frequency vs. temperature stability, referenced to 25 C.
4) After ten days of continuous operation.
5) Allen Variance: 1 second, 100 average.
6) Vcc = 3.3Vdc.
Labeling Diagram
7) From Vcc=90% of final value. No more than 16 transitions at start-up before oscillator
has started.
8) Measured @ -40 C, within 5 minutes, referenced one hour after turn-on.
9) After stabilization in a controlled airflow environment.
10) At time of delivery.
MODEL
FREQUENCY 10.000MHz
DATE CODE
CAL. FREQ.
OVC3CF4AA
0021
10.000000
11) LVCMOS load.
12) For a given off time, the time required to meet daily aging, short-term stability and TDEV
requirements.
Package Outline
.500
12.700mm
Solder Profile
Test Circuit
Ramp-Up Rate
3°C/second max.
from 150°C to 225°C.
Ramp-Down Rate
6°C/second max.
Temperature
225°C
225°C
tp
183°C
150°C
+3.3Vdc
100°C
25°C
CONTROL
VOLTAGE
(Vc)
0
Time
60-120s
Max.
10-30s
60-150s Max.
360 Sec. Max.
