Applications
OV9715
¬
¬
¬
Rear View/Backup Camera
360° View/Surround View
Blind Spot Detection
¬
¬
Night Vision/Dual Mode
Occupant Sensor
Ordering Information
¬ OV09715-F48V
(color, lead-free, 48-pin QFP2)
¬ OV09215-F48V
(B&W, lead-free, 48-pin QFP2)
Product Features
¬
¬
¬
high sensitivity for low-light operation
¬
support for horizontal and vertical
sub-sampling
ultra low power and low cost
Product Specifications
¬
¬
support for black sun cancellation
automatic image control functions:
- automatic exposure control (AEC)
- automatic gain control (AGC)
- automatic white balance (AWB)
- automatic band filter (ABF)
- automatic black level calibration
(ABLC)
standard serial camera control bus
(SCCB) interface
¬ active array size: 1280 x 800
¬ input clock frequency: 6 ~ 27 MHz
¬ power supply:
¬ scan mode: progressive
¬
¬
digital video port (DVP) parallel output
interface
- core: 1.5 VDC ±5% (built-in regulator)
- analog: 3.0 ~ 3.6 V
- I/O: 1.7 ~ 3.6 V
¬ maximum image transfer rate:
- WXGA (1280 x 800): 30 fps
- 640 x 400: 60 fps
embedded one-time programmable
(OTP) memory
¬
¬
programmable controls: frame rate,
AEC/AGC 16-zone size/position/
weight control, mirror, flip, cropping,
and windowing
¬ power requirements:
- active: 110 mW
¬ sensitivity: 3300 mV/(lux-sec)
¬ dynamic range: 69 dB
¬
¬
on-chip phase lock loop (PLL)
built-in 1.5V regulator for core
- standby: 50 µA
¬ temperature range:
- operating: -40° C to 85° C
- stable image: 0° C to 50° C
image quality controls: lens correction
and defective pixel canceling
¬ pixel size: 3 µm x 3 µm
¬ image area: 3888 µm x 2430 µm
¬
¬
output support for raw RGB
¬ output formats: 10-bit raw RGB data
¬ lens size: 1/4"
¬ package dimensions:
- QFP2: 12 mm x 12 mm
supports image sizes:
WXGA (1280x800) and 640x400
¬ sensor chief ray angle: 0°
Functional Block Diagram
OV9715/OV9215
image sensor core
sensor
processor
output
interface
column
sample/hold
array
10-bit
A/D
AMP
gain control
control register bank
SCCB slave interface
PLL
timing generator and system control logic
