Applications
OV7960
¬
Security and Surveillance Cameras
Ordering Information
Product Features
¬
OV07960-C48N
¬
¬
OV07461-C48N
(B&W, NTSC. lead-free, 48-pin CLCC)
(color, NTSC, lead-free, 48-pin CLCC)
¬
¬
¬
NTSC and PAL output
¬
¬
16 bytes of one-time programmable
memory (OTP) to control overlay and
set other customer variables
¬
OV07960-C48P
(color, PAL, lead-free, 48-pin CLCC)
OV07461-C48P
(B&W, PAL, lead-free, 48-pin CLCC)
high sensitivity
automatic exposure/gain with
16 zone control
SPI master for single static overlay
and loading setting
¬
horizontal and vertical windowing
capability
¬
¬
dynamic overlay controls
defective pixel correction
Product Specifications
¬
¬
¬
auto white balance control
aperture/gamma correction
¬
active array size:
- NTSC: 656 x 492
- PAL: 768 x 576
¬
¬
¬
lens chief ray angle: 0°
output formats: NTSC/PAL, CCIR656
external frame sync capability
(Genlock)
¬
power supply:
- core: 1.5 V
maximum image transfer rate:
- NTSC: 60 fields per second
- PAL: 50 fields per second
¬
slave compatible serial camera
control bus (SCCB) control interface
for register programming
- analog: 3.3 V
- I/ O: 1.8 ~ 3.3 V
¬
¬
sensitivity: >12 V/(lux-sec)
¬
¬
power requirements:
- active: 225 mV
¬
¬
low power consumption
pixel size: 6.0 µm x 6.0 µm
OmniPixel3-HS
extremely low dark current for high
temperature applications
temperature range:
- operating: -20°C to 70°C
- stable image: 0°C to 50°C
¬
¬
image area: 4752 µm x 3552 µm
¬
¬
50/60 Hz flicker cancellation
package dimensions:
14.22 mm x 14.22 mm
¬
optical size:
- NTSC: 1/3.6"
- PAL: 1/3"
overlay with four layers, 16 colors
and eight transparencies each
Functional Block Diagram
OV7960
image sensor
core
image sensor
processor
image output
interface
Y[9:0]
10-bit
ADC
array
AMP
VCON/VCOP
column
sample/hold
gain
control
mirror
PAL/NTSC
color/BW
control register bank
SCCB slave interface
timing generator and
system control logic
SPI master
interface
video
input
OSC
PLL
