This document was generated on 06/02/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
0988211069
Active
nscc
Overview:
Description:
3.33mm (.131") Pitch SCC Pin Housing for 1.5mm (.059") Tab, Non Sealed, 3 Circuits,
Brown
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Series
General
Product Family
Series
image - Reference only
China RoHS
Crimp Housings
98821
nscc
EU RoHS
Overview
ELV and RoHS
Compliant
Product Name
NSCC
Physical
Circuits (maximum)
Color - Resin
REACH SVHC
Not Reviewed
Halogen-Free
Status
6
Brown
Receptacle
Gender
Not Reviewed
Need more information on product
environmental compliance?
Glow-Wire Compliant
Keying to Mating Part
Lock to Mating Part
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Pitch - Term. Interface (in)
Pitch - Term. Interface (mm)
Polarized to Mating Part
Ports
No
None
Yes
1
Bag
No
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
0.131 In, 0.165 In, 0.196 In
3.33 mm, 4.20 mm, 5.00 mm
0.131 In, 0.165 In, 0.196 In
3.33 mm, 4.20 mm, 5.00 mm
Yes
1
Please visit the Contact Us section for any
non-product compliance questions.
Stackable
Temperature Range - Operating
No
Search Parts in this Series
98821Series
-40°C to +85°C
Material Info
Old Part Number
0104413211
Mates With
98825106x , 98770201x
Reference - Drawing Numbers
Sales Drawing
SD-98821-002
This document was generated on 06/02/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
