VTSRC, VSSRC, VSORC-AD
Vishay Thin Film
25 or 50 Mil Pitch, T-Filter Resistor/Capacitor Networks
FEATURES
• Lead (Pb)-free standard
• Resistors and capacitors on a single chip
RoHS
• Saves board space
COMPLIANT
Actual Size
• Reduces total assembly costs
• Uniform performance characteristics
• Compatible with automatic surface mounting equipment
• UL 94V-0 flame resistant
Small Outline, Surface Mount, EMI/RFI Reduction, T-Filter Networks
Vishay Thin Film’s schematic AD is designed as an 8
channel filter for use with personal computer and peripheral
110 ports such as SCSI ports. The use of single die
technology for filtering minimizes space and allows for more
freedom in routing. With a rugged molded case to protect
the circuit from the environment and an integrated thin film
network this product is your choice when reduced size,
improved accuracy and surface mount capability are your
goals.
• Rugged, molded case construction
TYPICAL PERFORMANCE
TCR
200
TOLERANCE
10 %
RESISTOR
Available packages SOIC, SSOP and TSSOP.
TCC
200
TOLERANCE
20 %
SCHEMATIC AD
CAPACITOR
20 19 18 17 16 15 14 13 12 11
MODELS
STANDARD VALUES
VSORC
VSSRC
VTSRC
R (Ω)
C (pF)
X
33
47
1
2
3
4
5
6
7
8
9
10
STANDARD ELECTRICAL SPECIFICATIONS
TEST
SPECIFICATIONS
CONDITIONS
Material
Tantalum Nitride on Silicon
Resistance Range
10 Ω to 750 Ω
10 ppm/ꢀC
Tracking
Absolute
Absolute
TCR:
200 ppm/ꢀC
0 ꢀC to + 70 ꢀC
10 ꢁ Standard (R)
Tolerance:
at 1 MHz and VRMS
over + 10 ꢀC to + 70 ꢀC
Absolute
Package
20 ꢁ Standard (C)
Power Rating:
Capacitance Range
Stability:
1 W - (T)SSOP. 1.2 W - SOIC
See Derating Curve
10 pF to 150 pF - TSSOP/10 pF to 250 pF - SOIC and SSOP
ΔR Ratio
2 ꢁ
> 2 kV
1000 h
ESD Protection
Breakdown Voltage
MIL-STD-883, Method 3015
35 - 50 V
Operating Temperature Range
Storage Temperature Range
Power Rating/Resistor
0 ꢀC to + 70 ꢀC
- 55 ꢀC to + 125 ꢀC
100 mW
Document Number: 60086
Revision: 01-Jul-08
