Programmed Oscillator · VX7
Programmed SMD Oscillator · 7.0 x 5.0 mm
■
■
■
■
fast delivery service
RoHS
tristate or stop function available
reflow soldering temperature: 260 °C max.
full ceramic package
2002/95/EC
actual size
RoHS compliant
Pb free: pins / pads
General Data
Table 1: Frequency Stability Code
type
VX7 3.3 V / 5.0 V
stability code
A
100 ppm
O
B
G
C
frequency range
1.0 ~ 200.0 MHz (15pF max.)
1.0 ~ 50.0 MHz (50pF max.)
25 ppm ~ 100 ppm (table 1)
see table 2
50 ppm
O
30 ppm
O
25 ppm
O
-10 °C ~ +70 °C
-40 °C ~ +85 °C
O available
STD.
T1
frequency stability over all*
current consumption
supply voltage VDC
temperature operating
storage
O
O
O
O
3.3 V 10ꢀ / 5.0 V 10ꢀ
* includes stability at 25 °C, operating temp. range, supply voltage change, shock and vibration, aging 1st year.
-10 °C ~ +70 °C / -40 °C ~ +85 °C
-55 °C ~ +125 °C
Table 2: Current Consumption max.
output
rise & fall time see table 3
Current at 15pF load
Current at 50pF load
5.0 V version:
30 mA with 15 pF load
3.3 V version:
50 mA with 50 pF load
5.0 V version:
3.3 V version:
load max
15pF / 50pF
20 mA with 15 pF load
30 mA
50 mA
3.3 V version:
20 mA
30 mA
30 mA with 50 pF load
current max.
8mA (3.3 V) / 16 mA (5.0 V)
5.0 V version:
low level max. 0.1 x VDC
high level min. 0.9 x VDC
standby function
stop / tristate
Table 3: Rise & Fall Time max.
output enable time max.
output disable time max.
start-up time max.
10ms / 100 ns
6.0 ns: 1.0 ~ 49.9 MHz
5.0 ns: 50.0 ~ 99.9 MHz
4.0 ns: 100.0 ~ 200.0 MHz
note:
100ns
- specific data on request
10ms
- rise time: 0.1 VDC ~ 0.9 VDC
- fall time: 0.9 VDC ~ 0.1 VDC
symmetry at 0.5 x VDC
45ꢀ ~ 55ꢀ typ. (40ꢀ ~ 60ꢀ max.)
Dimensions
0.1
1.8
0.2
0.1
7.0
1.4
# 4 # 3
J...
# 3
# 4
pin connection
# 1: e/d
# 2: ground
# 3: output
# 4: VDC
# 1 # 2
# 2
# 1
0.1
5.08
0.1
5.08
in mm
top view
side view
bottom view
pad layout
Order Information
supply voltage
code
output load
code
option
frequency
in MHz
type
VX7
frequency stability
code
O
Oscillator
1.0 ~ 200.0 MHz (15 pF)
1.0 ~ 50.0 MHz (50 pF)
A = 100 ppm
B = 50 ppm
G = 30 ppm
C = 25 ppm
3.3 = 3.3 V
5.0 = 5.0 V
1 = 15 pF
3 = 50 pF
blank = -10 °C ~ +70 °C
T1 = -40 °C ~ +85 °C
blank = tristate function
STP = stop function
Example: O 20.0-VX7-B-3.3-1 (LF = RoHS compliant / Pb free pins or pads)
•
Jauch Quartz GmbH e-mail: info@jauch.de
full data can be found under: www.jauch.de / www.jauch.co.uk / www.jauch.fr / www.jauchusa.com
All specifications are subject to change without notice
040909
