Mixer
The content of this specification may change without notification 7/01/09
Mixer
P/N: JXWBHP-T-3000-4000-12
IF Frequency(GHz)
RF Frequency(GHz)
LO Frequency(GHz)
LO Power (dBm)
3.0~4.0
3.0~4.0
0.1~1.0
12
LO-RF Isolation(dB)
LO-IF Isolation(dB)
Conversion Loss(dB)
Pout @1dB(dBm)
Connector
Operating Temperature(ºC)
Storage Temperature(ºC)
Net Weight(Kg)
30 min
27 min
8
+6
SMA-Female
-40~+80
-55~+85
0.055 Around
Outline Drawing (Size: mm)
For current data sheets, please contact: sales@aacix.com
188 Technology Drive, Unit H, Irvine, CA 92618
