IXFN260N17T
Symbol
Test Conditions
Characteristic Values
SOT-227B (IXFN) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 60A, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
105
170
S
Ciss
Coss
Crss
24
2870
450
nF
pF
pF
td(on)
tr
td(off)
tf
54
40
90
40
ns
ns
ns
ns
Resistive Switching Times
V
GS = 15V, VDS = 0.5 • VDSS, ID = 100A
RG = 1Ω (External)
Qg(on)
Qgs
400
108
116
nC
nC
nC
(M4 screws (4x) supplied)
VGS = 10V, VDS = 0.5 • VDSS, ID = 130A
Qgd
RthJC
RthCS
0.138 °C/W
°C/W
0.05
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min. Typ.
Max.
IS
VGS = 0V
260
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = 60A, VGS = 0V, Note 1
IF = 130A, VGS = 0V
1040
1.3
trr
QRM
200 ns
0.56
9.00
μC
-di/dt = 100A/μs
VR = 75V
IRM
A
Note 1: Pulse Test, t ≤ 300μs; Duty Cycle, d ≤ 2%.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
