IXFH18N90P IXFV18N90P
IXFT18N90P IXFV18N90PS
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
Gate Input Resistance
6
10
S
RGi
1.2
Ω
Ciss
Coss
Crss
5230
366
53
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
40
33
60
44
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 2Ω (External)
Qg(on)
Qgs
97
30
40
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
0.23 °C/W
°C/W
(TO-247, PLUS220)
0.25
Source-Drain Diode
Characteristic Values
TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
18
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
72
1.5
trr
300 ns
IF = 9A, -di/dt = 100A/μs
QRM
IRM
1.0
μC
VR = 100V, VGS = 0V
10.8
A
Note 1. Pulse test, t ≤ 300μs; duty cycle, d ≤ 2%.
