• 1N5822US AVAILABLE IN JAN, JANTX, JANTXV AND JANS
PER MIL-PRF-19500/620
1N5820US
thru
1N5822US
• 3 AMP SCHOTTKY BARRIER RECTIFIERS
• HERMETICALLY SEALED
• LEADLESS PACKAGE FOR SURFACE MOUNT
• METALLURGICALLY BONDED, DOUBLE PLUG CONSTRUCTION
MAXIMUM RATINGS
Operating Temperature: -65°C to +125°C
Storage Temperature: -65°C to +150°C
Average Rectified Forward Current: 3.0 AMP, T
= +55°C
EC
Derating: 43 mA / °C above T
= +55°C
EC
MILLIMETERS
INCHES
DIM MIN
MAX
3.76
0.71
5.72
MIN MAX
.137 .148
0.019 0.028
.200 .225
.001MIN.
D
F
G
3.48
0.48
5.08
S
0.03MIN.
FIGURE 1
ELECTRICAL CHARACTERISTICS @ 25°C, unless otherwise specified.
CDI
TYPE
NUMBER
WORKING PEAK
REVERSE
VOLTAGE
MAXIMUM REVERSE
LEAKAGE CURRENT
AT RATED VOLTAGE
DESIGN DATA
MAXIMUM FORWARD VOLTAGE
CASE: D-5B, Hermetically sealed glass
V
V
V
V
I
I
RWM
F @ 1.0A
VOLTS
0.40
F @ 3.0A
VOLTS
0.50
F @ 9.4A
VOLTS
0.70
R @ 25°C
mA
R @ 100°C
case, PER MIL-PRF 19500/620
VOLTS
20
mA
12.5
12.5
12.5
12.5
1N5820US
1N5821US
1N5822US
0.10
LEAD FINISH: Tin / Lead
30
0.40
0.50
0.70
0.10
40
0.40
0.50
0.70
0.10
J,JX, JV & JS
5822US
40
0.40
0.50
0.70
0.10
THERMAL RESISTANCE: (R
10 ˚C/W maximum at L = 0 inch
):
OJEC
THERMAL IMPEDANCE: (Z
): 3
OJX
˚C/W maximum
POLARITY: Cathode end is banded.
MOUNTING SURFACE SELECTION:
The Axial Coefficient of Expansion
(COE) of this device is approximately
+ 4PPM / °C. The COE of the Mounting
Surface System should be selected to
provide a suitable match with this
device.
