Triple-B a la n c ed M ix er
M Y 5 0 /M Y 5 0 C
V 2
Features
Product Image
ñ
ñ
ñ
ñ
ñ
ñ
LO 2.0 to 26 GHz
RF 2.0 to 26 GHz
IF 1.0 to 15 GHz
LO Drive +10 dBm (nominal)
High Compression Point
Very W ide Bandwidth
Description
MY50 is a triple balanced mixer, designed for use in military, com-
mercial and test equipment applications. The design utilizes
Schottky ring quad diodes and broadband soft dielectric baluns to
attain excellent performance. The use of high temperature solder
assembly processes used internally makes it ideal for use in man-
ual, semi-automated assembly. Environmental screening avail-
able to MIL-STD-883, MIL-STD-202 or MIL-DTL-28837, consult
factory.
Ordering Information
Part Number
Package
MY50
Versapac
MY50C
SMA Connectorized
Electrical Specifications: Z0 = 50W Lo = +10 dBm (Downconverter Application only)
Typical
Guaranteed
Parameter
Test Conditions
Units
+25ºC
-54º to +85ºC
SSB Conversion Loss
(max)
fR = 2.5 to 18 GHz, fL = 2 to 18 GHz, fI = 2 to 10 GHz
fR = 2 to 18 GHz, fL = 2 to 26 GHz, fI = 2 to 12 GHz
fR = 2 to 26 GHz, fL = 2 to 26 GHz, fI = 1 to 15 GHz
7.5
8.0
9.0
9.5
10.5
11.5
10.0
11.0
12.0
dB
SSB Noise Figure (max)
Isolation, L to R (min)
W ithin 1 db of conversion loss
dB
dB
____
____
____
fL = 2 to 3 GHz
fL = 3 to 26 GHz
30
22
20
15
18
13
fL = 2 to 7 GHz
fL = 7 to 26 GHz
30
22
20
15
18
13
Isolation, L to I (min)
dB
1 dB Conversion Comp.
fL = +10 dBm
dBm
+5
fR1 = 5 GHz a t œ6 d B m , fR2 = 5.01 GHz a t œ6 d B m , fL = 8 GHz a t + 10 d B m
fR1 = 25 GHz a t œ6 d B m , fR2 = 25.01 GHz a t œ6 d B m , fL = 15 GHz a t + 10
d B m
+15
+15
Input IP3
dBm
1
