Preliminary
Product Description
STM-2116
The Sirenza Microdevices’ STM-2116 is a high linearity
active mixer for use in a wide variety of communication
systems covering the 1800-2100 MHz frequency bands.
This device operates from a single 5V supply and provides
16 dB of conversion gain while requiring only 0dBm input
to the integrated LO driver. The STM-2116 also includes an
integrated on chip IF amplifier and is fabricated using Sili-
con Germanium (SiGe) device technology.
1800 - 2100 MHz High Linearity
Active Transmit Mixer
The RF and LO ports can be driven differential or single
ended. Each broadband port has been designed to mini-
mize performance degradation while operating into highly
reactive components such as SAW filters. The device is
packaged in an industry standard 16 pin TSSOP with
exposed paddle for superb RF and thermal ground.
16 pin TSSOP with Exposed Ground Pad
Package Footprint: 0.197 x 0.252 inches (5.0 x 6.4 mm)
Package Height: 0.039 inches (1.0 mm)
Product Features
• Active mixer with 16 dB conversion gain
Functional Block Diagram
• Integrated 0dBm LO drive and IF amplifier
• Differential or single-ended input
• Single supply operation (+5V)
• Broadband resistive 50Ω impedance on all
three ports
VEE
VCC
VEE
RFN
RFP
VEE
VCC
IFN
1
2
3
4
5
6
7
8
16 VEE
15 VCC
14 VEE
13 LON
12 LOP
11 VEE
10 VCC
• Low LO-RF leakage
Applications
• Cellular/PCS/CDMA2000 transmitters
9
IFP
Product Specifications
Test Conditions: TA = 25ºC, VCC = 5.0V,
Parameters
P
LO = 0dBm, PIF = -20dBm, IF =
Unit
Min.
Typ.
Max.
Min.
Typ.
Max.
200MHz
RF Frequency Range
LO Frequency Range
IF Frequency Range
Conversion Gain
SSB Noise Figure
Output IP3
MHz
MHz
MHz
dB
1800
1600
30
2000
1800
400
19
2000
1800
30
2100
2000
400
18
200
17
200
16
15
13
dB
9.5
24
11
9.5
21
11
IF1 = IF2 = -20 dBm/tone, 1 MHz spacing
dBm
dBm
dBm
dBm
dB
20
8
17
6
Output P1dB
11
9
Leakage (LO-RF)
Leakage (LO-IF)
-20
-45
14
-10
-35
-20
-45
14
-10
-35
RF, LO, IF Return Loss Matched to 50Ω, see Note 1, page 3
Supply Voltage (Vcc)
V
+4.75
-3
+5.0
200
0
+5.25
+3
+4.75
-3
+5.0
200
0
+5.25
+3
Supply Current
mA
LO Drive
Matched to 50Ω
dBm
ºC/W
Thermal Resistance
junction-case
25
25
