Advance Technical Information
IXGE 200N60B
V
= 600 V
= 175 A
= 2.1 V
HiPerFASTTM IGBT
CES
I
C25
V
CE(sat)
E
ISOPLUS227TM (IXGE)
E Q
Symbol
TestConditions
Maximum Ratings
G
VCES
VCGR
TJ = 25°C to 150°C
600
600
V
V
TJ = 25°C to 150°C; RGE = 1 MΩ
VGES
VGEM
Continuous
Transient
±20
±30
V
V
E Q
C
IC25
IC90
ICM
TC = 25°C
175
112
400
A
A
A
G = Gate, E = Emitter, C = Collector
TC = 90°C
TC = 25°C, 1 ms
Q
either emitter terminal can be
used as Main or Kelvin Emitter
SSOA
(RBSOA)
VGE = 15 V, TVJ = 125°C, RG = 2.4 Ω
Clamped inductive load, L = 30 µH
ICM = 200
@ 0.8 VCES
A
Features
PC
TC = 25°C
500
W
•Conforms to SOT-227B outline
•Isolation voltage 3000 V~
•Very high current, fast switching IGBT
TJ
-40 ... +150
150
°C
°C
°C
TJM
Tstg
-40 ... +150
•Low VCE(sat)
VISOL
50/60 Hz
ISOL ≤ 1 mA
t = 1 min
t = 1 s
2500
3000
V~
V~
- for minimum on-state conduction
losses
I
•MOS Gate turn-on
Md
Mounting torque
Terminal connection torque (M4)
1.5/13 Nm/lb.in.
1.5/13 Nm/lb.in.
- drive simplicity
•Low collector-to-case capacitance
(< 50 pF)
Weight
19
g
•Low package inductance (< 5 nH)
- easy to drive and to protect
Applications
Symbol
TestConditions
Characteristic Values
(TJ = 25°C, unless otherwise specified)
•AC motor speed control
•DC servo and robot drives
•DC choppers
min. typ. max.
BVCES
VGE(th)
IC = 1 mA , VGE = 0 V
IC = 1 mA, VCE = VGE
600
2.5
V
V
•Uninterruptible power supplies (UPS)
5.5
•Switch-mode and resonant-mode
power supplies
ICES
VCE = VCES
VGE = 0 V
TJ = 25°C
TJ = 125°C
200
2
µA
mA
Advantages
IGES
VCE = 0 V, VGE = ±20 V
±400
nA
V
•Easy to mount with 2 screws
•Space savings
VCE(sat)
IC = 120A, VGE = 15 V
2.1
•High power density
98911 (2/02)
© 2002 IXYS All rights reserved
