Preliminary
®
XTL1005
•
•
•
Surface Mount Seam Weld Package
Excellent Reliability Performance
Good Frequency Perturbation and Stability over Temperature
9.84375 MHz
Crystal Unit
The XTL1005 is a surface mount 5.0 x 3.2 mm crystal unit for use in wireless telecommunica-
tions devices, especially for a need of ultra miniature package for mobility.
SM5032-4 Case
Electrical Characteristics
Characteristic
Sym
Notes
Minimum
Typical
Maximum
Units
Nominal Frequency
Mode of Oscillation
9.843750
MHz
Fundamental
Storage Temperature Range
-40
-40
+125
+125
°C
°C
Operating Temperature Range
Frequency Stability over Operating Temperature Range
Frequency Make Tolerance
±50ppm (referred to the value at 25°C)
FL
±50ppm at 25°C ±3°C
Equivalent Series Resistance
Nominal Drive Level
ESR
100
W
uW
pF
pF
10
Shunt Capacitance
Co
CL
5
Load Capacitance
3
Lid Symbolization (in addition to Lot and/or Date Codes)
1005 YWWS
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
Notes:
1. The design, manufacturing process, and specifications of this device are subject to change without notice.
