Specifications
■ Coil Ratings
Rated voltage
Set coil
Reset coil
Must-set Must-
Max.
voltage
Power
consumption
(Approx.)
voltage
reset
voltage
Rated current
Resistance
Rated current
Resistance
% of rated voltage
Set coil
Reset
coil
50 Hz
60 Hz
50 Hz
60 Hz
AC
12 V
24 V
57 mA
56 mA
72 Ω
39 mA
38.2 mA 130 Ω
80%
max.
80%
max.
110%
0.6 to 0.9 0.2 to 0.5
(60 Hz)
(60 Hz)
27.5 mA 26.4 mA 320 Ω
14.0 mA 13.4 mA 1,400 Ω
7.1 mA 6.9 mA 5,400 Ω
18.6 mA 18.1 mA 550 Ω
3.5 mA 3.4 mA 3,000 Ω
3.5 mA 3.4 mA 3,000 Ω
50 V
100 V
DC 12 V
24 V
110 mA
52 mA
110 Ω
470 Ω
50 mA
25 mA
235 Ω
940 Ω
1.3 W
0.6 W
Note: 1. For AC models, the rated current values are half-wave rectified current values measured with a DC ammeter.
2. The rated current and coil resistance are measured at a coil temperature of 23°C with tolerances of +15%/–20% for AC rated current and
±15% for DC rated current, and +15% for DC coil resistance.
3. The AC coil resistance values are for reference only.
4. Performance characteristic data are measured at a coil temperature of 5°C to 35°C.
■ Contact Ratings
Item
Resistive load (cosφ = 1)
3 A at 220 VAC, 3 A at 24 VDC
Inductive load (cosφ = 0.4) (L/R = 7 ms)
Rated load
0.8 A at 220 VAC, 1.5 A at 24 VDC
Rated carry current
3 A
Max. switching voltage
Max. switching current
Max. switching power
Failure rate* (reference value)
250 VAC, 125 VDC
3 A
660 VA, 72 W
1 mA at 1 VDC
176 VA, 36 W
*Note:
P level: λ60 = 0.1 x 10-6/operation
■ Characteristics
Contact resistance
50 mΩ max.
Time:
Set time
AC: 30 ms max.; DC: 15 ms max.
Min. pulse width:
Time:
AC: 60 ms.; DC: 15 ms.
Reset time
AC: 30 ms max.; DC: 15 ms max.
AC: 60 ms.; DC: 15 ms.
Min. pulse width:
Max. operating frequency
Mechanical: 18,000 operations/hr
Electrical: 1,800 operations/hr (under rated load)
Insulation resistance
Dielectric strength
100 MΩ min. (at 500 VDC)
1,500 VAC, 50/60 Hz for 1 min (1,000 VAC between contacts of same polarity and between set and reset
coils)
Vibration resistance
Shock resistance
Destruction: 10 to 55 to 10 Hz, 0.5 mm single amplitude (1.0 mm double amplitude)
Malfunction: 10 to 55 to 10 Hz, 0.5 mm single amplitude (1.0 mm double amplitude)
Destruction: 1,000 m/s2
Malfunction: 200 m/s2
Endurance
Mechanical: 100,000,000 operations min. (at 18,000 operations/hr)
Electrical: 200,000 operations min. (at 1,800 operations/hr)
Ambient temperature
Ambient humidity
Weight
Operating: –55°C to 60°C (with no icing)
Operating: 5% to 85%
Approx. 30 g
Note: The data shown above are initial values.
General-purpose Latching Relay MYK
